System And Components
198-9892 LINES GP-FUELS/N CEZ1-399
Group No: 198-9892
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4961 | 1 CLAMP-HOSE | 3 | |
| 6V8367 | 2 LOCKWASHER | 1 | |
| 8T6724 | 3 VALVE-BALL (FUEL RETURN) | 1 | |
| 8W2746 | 4 HOSE AS | 1 | |
| 1486870 | 5 HOSE AS | 1 | |
| 1498142 | 6 CONNECTOR | 1 | |
| 1590225 | 7 HOSE AS | 1 | |
| 1997686 | 8 HOSE AS | 1 | |
| 1997823 | 9 HOSE AS | 1 | |
| 0338248 | 10 CLIP (LOOP) | 1 | |
| 1004336 | 11 CLIP (LOOP) | 3 | |
| 1488340 | 12 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488367 | 13 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488377 | 14 ELBOW AS | 1 | |
| 6V8980 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1488393 | 15 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488439 | 16 TEE AS | 1 | |
| 6V8774 | TEE | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488444 | 17 TEE AS-SWIVEL | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1504037 | 18 TEE AS | 1 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1716728 | 19 ELBOW AS | 1 | |
| 8T0249 | ELBOW (SWIVEL) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1P4278 | 20 CLAMP-HOSE | 1 | |
| 1S0994 | 21 CLIP (LOOP) | 15 | |
| 1S6420 | 22 CLIP | 2 | |
| 2H3924 | 23 LOCKWASHER | 1 | |
| 3K0360 | 24 SEAL-O-RING | 2 | |
| 4L6454 | 25 BOLT (3/8-16X1-IN) | 2 | |
| 5M3062 | 26 BOLT (3/8-16X0.75-IN) | 21 | |
| 5P4295 | 27 CLIP | 1 | |
| 5P8502 | 28 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 8Y6364 | SLEEVE | 1 | |
| 6V1889 | 29 CLIP (LOOP) | 2 | |
| 6V8398 | 30 SEAL-O-RING | 2 | |
| 6V8801 | 31 NUT (3/8-16-THD) | 1 | |
| 6V9168 | 32 NUT (11/16-16-THD) | 1 | |
| 6V9170 | 33 NUT-BULKHEAD (1-14-THD) | 1 | |
| 6V9796 | 34 ELBOW | 1 | |
| 7D7233 | 35 CLIP (LOOP) | 1 | |
| 7J9108 | 36 SEAL-O-RING | 1 | |
| 8M2773 | 37 CLIP (LOOP) | 12 | |
| 8T4179 | 38 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4896 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 8T5464 | 41 VALVE-BALL (FUEL SUPPLY) | 1 | |
| 8C6959 | 42 HOSE (139CM) | ||
| 5P1442 | 43 HOSE (96CM EACH) | ||
| 5P1442 | 43A HOSE (36CM) |
