System And Components
190-6784 LINES GP-FUEL FILTERS/N 4ZF23605-25503
Group No: 190-6784
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P1232 | 1 BRACKET | 1 | |
| 0839527 | 2 SPACER (13X20X1.5-MM THK) | 1 | |
| 0922467 | 3 SPACER (10.5X2X45-MM THK) | 1 | |
| 1266872 | 4 TEE | 1 | |
| 1833398 | 5 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 1833403 | 6 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 1833406 | 7 PLUG AS | 3 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 1861667 | 8 CONNECTOR AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 1906785 | 9 BRACKET AS | 1 | |
| 1907383 | 10 TUBE AS | 1 | |
| 1998037 | 11 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2051306 | 12 REGULATOR GP-FUEL PRESSURE | 1 | |
| 2130064 | 13 BASE AS (FUEL) | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2331752 | 14 TUBE AS | 1 | |
| 2396290 | 15 HOSE AS | 1 | |
| 2580883 | 16 SWITCH GP-PRESSURE (DIFFERENTIAL) | 1 | |
| 2609235 | 17 VALVE AS-BALL | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2609233 | VALVE-BALL | ||
| 2609236 | 18 VALVE AS-BALL | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2609234 | VALVE-SHUTOFF | 1 | |
| 1R0762 | 19 FILTER-FUEL (ADVANCED EFFICIENCY) | 1 | |
| 2R6806 | 20 CONNECTOR | 1 | |
| 2Y5829 | 21 NUT (M10X1.5-THD) | 1 | |
| 3E4353 | 22 WASHER-HARD (11X25X3-MM THK) | 3 | |
| 3S2093 | 23 STRAP-CABLE | 1 | |
| 4D7735 | 24 CLIP | 1 | |
| 4P7581 | 25 CLIP (LADDER) | 1 | |
| 5P9297 | 26 CLIP (LOOP) | 1 | |
| 6V3265 | 27 CLIP | 1 | |
| 6V3822 | 28 BOLT (M10X1.5X35-MM) | 1 | |
| 6V4248 | 29 BOLT (M10X1.5X25-MM) | 7 | |
| 6V5049 | 30 SEAL-O-RING | 3 | |
| 6V5839 | 31 WASHER (11X21X2.5-MM THK) | 8 | |
| 6V5844 | 32 BOLT (M16X2X35-MM) | 3 | |
| 6V6317 | 33 BOLT (M10X1.5X20-MM) | 1 | |
| 6V7981 | 34 BOLT (M10X1.5X70-MM) | 1 | |
| 8L2779 | 35 SEAL-O-RING | 1 | |
| 8T0151 | 36 ADAPTER | 1 | |
| 9X8268 | 37 WASHER (17.5X30X3.5-MM THK) | 3 |
