213-6224 WIRING GP-SCRAPERS/N CEZ1-399

Group No: 213-6224

Part Number	Part Name	Qty
2G0024	1 BRACKET AS	1
3E5239	2 RELAY AS (24-VOLT)(MAIN)	1
5N2126	3 CONNECTOR (THERMOCOUPLE)	1
6V4283	4 PLATE-IDENTIFICATION (ALTERNATOR RESET)	1
9F8125	5 LOCKWASHER	2
9X3271	6 ADAPTER (1/2-14-THD)	1
1251302	7 SWITCH GP-MAGNETIC (24-VOLT)(CIRCUIT BREAKER)	1
1256390	8 PLATE-INFORMATION (ENGINE)	3
1310784	9 SENSOR GP-TEMPERATURE (TRACTOR CONVERTER OIL)	1
1619926	10 SENSOR GP-PRESSURE (TURBO INLET)	1
1655970	11 SWITCH GP-TOGGLE (PRIMING PUMP)	1
1712205	12 CIRCUIT BREAKER AS (40-AMPERE)(ALTERNATOR)	1
1H3244	LOCKWASHER	2
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
1753687	13 BRACKET AS	1
1806356	14 BRACKET	1
1933973	15 STRAP-CABLE	5
2005332	16 PLATE AS	1
2005335	17 COVER	1
2027724	18 CABLE AS	1
1S4915	LINER (CONDUIT)	2
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
5P0695	CONDUIT (68-CM)
5P0761	CABLE (00-GA, RED)(89-CM)
8N0869	COVER-TERMINAL (RED)	2
8T2225	TUBE-HEAT SHRINK (25.4-MM DIA)
2048000	19 MOUNTING-CABLE TIE	5
2052908	20 PLATE AS	1
2055399	21 HARNESS AS-BOX	1
2056307	22 RECEPTACLE AS	1
1S4915	LINER (CONDUIT)	4
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
5P0695	CONDUIT (170-CM)
8N0869	COVER-TERMINAL (RED)	1
8T2225	TUBE-HEAT SHRINK (25.4-MM DIA)
9G8909	COVER-TERMINAL (BLACK)	1
1598049	CABLE (00-GA, RED)(110-CM)
1598050	CABLE (00-GA, BLACK)(170-CM)
2136222	23 HARNESS AS-ENGINE	1
3E5519	PLUG AS-CONNECTOR (5-PIN)	1
1607689	PLUG AS-CONNECTOR (70-PIN)	1
9X0141	PLUG AS-CONNECTOR (40-PIN)	1
1552260	KIT-CONNECTING PLUG (3-PIN)	1
1552270	KIT-CONNECTING PLUG (2-PIN)	3
1552271	KIT-CONNECTING PLUG (4-PIN)	2
9X0145	RECEPTACLE AS-CONNECTOR (24-PIN)	1
1028803	KIT-RECEPTACLE (3-PIN)	1
1028801	KIT-RECEPTACLE (12-PIN)	1
2136223	24 HARNESS AS-TRANSMISSION	1
6D8149	PLUG AS-CONNECTOR (10-PIN)	1
1471446	PLUG AS-CONNECTOR (70-PIN)	1
1607690	PLUG AS-CONNECTOR (70-PIN)	1
7X6222	PLUG AS-CONNECTOR (24-PIN)	2
1552270	KIT-CONNECTING PLUG (2-PIN)	3
1028802	KIT-RECEPTACLE (2-PIN)	3
2197224	25 PLATE AS	1
0338248	26 CLIP (LOOP)	1
1241479	27 CLIP (LOOP)	2
1305300	28 CLIP	6
1470385	29 CLIP	1
1H4393	30 LOCKWASHER	6
1S0994	31 CLIP (LOOP)	2
2S9556	32 SCREW-MACHINE (10-32X0.875-IN)	2
3J1907	33 SEAL-O-RING	1
3J7354	34 SEAL-O-RING	1
8M2770	35 CLIP (LOOP)	8
4L6454	36 BOLT (3/8-16X1-IN)	11
4P7581	37 CLIP (LADDER)	3
4P8134	38 CLIP (LADDER)	1
4S1962	39 CLIP (LOOP)	2
5G6505	40 WASHER (25X38X14-MM THK)	3
5M3062	41 BOLT (3/8-16X0.75-IN)	29
5S7349	42 BOLT (1/4-20X0.5-IN)	3
5S7379	43 BOLT (3/8-16X0.875-IN)	2
6D4244	44 CLIP (LOOP)	3
6T3642	45 CIRCUIT BREAKER AS (10-AMPERE)(TRANSMISSION)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
6T3643	46 CIRCUIT BREAKER AS (15-AMPERE)(ENGINE CONTROL)	1
6T3643	46A CIRCUIT BREAKER AS (15-AMPERE)(MAIN)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
6V7345	47 SCREW-MACHINE (8-32X0.875-IN)	6
6V8188	48 NUT (1/2-13-THD)	6
6V8801	49 NUT (3/8-16-THD)	4
7K1181	50 STRAP-CABLE	15
7X0599	51 WASHER-HARD (13X20X2-MM THK)	6
8C6358	52 BLOCK AS-JUNCTION (BATTERY)	1
1D5117	NUT-JAM (1/2-13-THD)	3
8T3519	BOLT-BRONZE (1/2-13X2-IN)	3
8M2773	53 CLIP (LOOP)	2
8S2634	54 COVER AS	1
2P2975	SEAL-O-RING	2
8T4121	55 WASHER-HARD (11X21X2.5-MM THK)	2
8T4189	56 BOLT (M8X1.25X20-MM)	2
8T4196	57 BOLT (M10X1.5X35-MM)	1
8T4205	58 WASHER-HARD (7.2X14.5X2-MM THK)	3
8T4896	59 WASHER-HARD (10.2X18.5X2.5-MM THK)	46
8T9405	60 BOLT-SOCKET HEAD (M4X0.7X16-MM)	4
9B7237	61 BOLT (3/8-16X1.25-IN)	2
6V1889	62 CLIP (LOOP)	1
9X8250	63 CLIP (LOOP)	2
4D7794	65 CLIP	1
5S7382	66 BOLT (3/8-16X1.375-IN)	1
