System And Components
336-8238 COOLER GP-TRANSMISSION OILS/N 4ZF12500-UP
Group No: 336-8238
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S0795 | 1 GASKET | 2 | |
| 8M9307 | 2 PLUG | 1 | |
| 8S4304 | 3 BONNET-XMSN OIL COOLER | 1 | |
| 1378480 | 4 CORE AS | 1 | |
| 8T6764 | PLUG-PIPE (1/8-27-THD) | 1 | |
| 1803907 | 5 SEAL-INTEGRAL | 1 | |
| 1983462 | 6 DIVERTER | 1 | |
| 2178723 | 7 ELBOW | 1 | |
| 2188557 | 8 BRACKET | 1 | |
| 1A5822 | 9 BOLT (1/2-13X2.75-IN) | 2 | |
| 1B2886 | 10 BOLT (1/2-13X3.75-IN) | 4 | |
| 1488407 | 11 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 6F7062 | 12 WASHER (12.7X19.05X1.83-MM THK) | 1 | |
| 6V3668 | 13 BOLT (M12X1.75X30-MM) | 2 | |
| 6V7981 | 14 BOLT (M10X1.5X70-MM) | 3 | |
| 7B3235 | 15 BOLT (1/2-13X1.375-IN) | 4 | |
| 7D1649 | 16 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 8T6761 | 17 PLUG-PIPE (1-11-1/2 NPT THD) | 2 | |
| 8T7950 | 18 BOLT (M10X1.5X180-MM) | 3 | |
| 9X8873 | 19 BOLT (1/2-13X2.25-IN) | 2 |
