System And Components
9G-0951 GEAR & CASE GP-TRANSFERS/N CWK1-UP; DRX1-UP
Group No: 9G-0951
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P8199 | 1 GASKET | 1 | |
| 3B0039 | 2 COVER | 1 | |
| 8B9777 | 3 GASKET | 1 | |
| 6V8801 | 4 NUT (3/8-16-THD) | 4 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 58 | |
| 7S2946 | 6 RETAINER | 1 | |
| 1P8198 | 7 COVER AS-CASE | 1 | |
| 7M7794 | STUD-WELD (9.4X21.5X25.5-MM) | 4 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 19 | |
| 3T8364 | 9 CONTROL GP-TRANSMISSION HYD | 1 | |
| 9G1236 | 10 CASE & PARTS GP-PLANETARY | 1 | |
| 8M8551 | 11 VALVE GP-RELIEF (TRANSMISSION LUBRICATION) | 1 | |
| 8M8621 | 12 GASKET | 1 | |
| 0S1619 | 13 BOLT (3/8-16X3-IN) | 4 | |
| 9W5353 | 14 RACE-ROLLER BEARING | 1 | |
| 1367813 | 15 RACE-BEARING | 1 | |
| 9G0315 | 16 PINION-BEVEL (30-TEETH) | 1 | |
| 7G7178 | 17 SHIM PACK (INCLUDES 6-SHIMS)(EACH) | 4 | |
| 7G8111 | 18 CAGE-BEARING | 1 | |
| 6V2304 | 19 BEARING AS-ROLLER | 1 | |
| 7G7057 | 20 PLATE-RETAINER | 1 | |
| 9M1974 | 21 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 4B3388 | 22 BOLT (5/16-18X1.125-IN) | 6 | |
| 9G0953 | 23 PLANETARY GP-TRANSMISSION | 1 | |
| 3P8218 | 24 RING-LOCK | 1 | |
| 0L2072 | 25 CLIP | 1 | |
| 4F4879 | 26 BOLT (3/8-16X0.5-IN) | 1 | |
| 0S1588 | 27 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1590 | 28 BOLT (3/8-16X2-IN) | 16 | |
| 7G8109 | 29 COVER-TRANSFER GEAR | 1 | |
| 9G0314 | 30 GEAR-BEVEL (42-TEETH) | 1 | |
| 6V6640 | 31 SEALANT | 1 | |
| 5P1777 | 32 RACE-BEARING OUTER | 1 | |
| 5P1776 | 33 RACE & ROLLER AS | 1 | |
| 7S2964 | 34 SHAFT-ANGLE DRIVE | 1 | |
| 0308535 | 35 BOLT-LOCKING (3/8-16X0.875-IN) | 4 | |
| 1P2561 | 36 PLATE | 1 | |
| 1P2566 | 37 CUP-BEARING | 2 | |
| 1P2567 | 38 CONE-BEARING | 2 | |
| 2K8257 | 39 SEAL-O-RING | 1 | |
| 7G7145 | 40 SHIM PACK (INCLUDES 6-SHIMS)(EACH) | 4 | |
| 1P2562 | 41 CAGE AS | 1 | |
| 2D6642 | BALL | 1 | |
| 2H2665 | 42 SEAL-O-RING | 1 | |
| 3S1262 | 43 RETAINER | 2 | |
| 0L1558 | 44 BOLT (1/2-20X3.25-IN) | 2 | |
| 8S6370 | 45 YOKE | 1 | |
| 0S1591 | 46 BOLT (3/8-16X1.5-IN) | 6 | |
| 0S1585 | 47 BOLT (1/2-13X1.5-IN) | 13 | |
| 5P8245 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 22 | |
| 7B3235 | 49 BOLT (1/2-13X1.375-IN) | 8 | |
| 1D4719 | 50 NUT-FULL (1/2-13-THD) | 1 | |
| 8M4437 | 51 SEAL-O-RING | 3 | |
| 2S0486 | 52 SLEEVE | 1 | |
| 9G9827 | 53 TUBE AS | 1 | |
| 5K9241 | 54 ELBOW | 1 | |
| 2S4957 | 55 SLEEVE | 1 | |
| 2160273 | 56 SEAL-LIP TYPE | 1 | |
| 1F5546 | 57 DOWEL | 1 | |
| 0L1026 | 58 PLUG-CUP | 1 | |
| 1305300 | 59 CLIP | 1 |
