System And Components
214-4634 LINES GP-RETARDERS/N CEZ1-UP
Group No: 214-4634
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T9518 | 1 HOSE AS | 1 | |
| 5T9520 | 2 HOSE AS | 1 | |
| 7D2533 | 3 TUBE AS | 1 | |
| 7D2534 | 4 TUBE AS | 1 | |
| 8E3431 | 5 PLATE | 1 | |
| 8W0580 | 6 BLOCK | 1 | |
| 1644215 | 7 VALVE GP-RETARDER HYD CONTROL | 1 | |
| 3217076 | 8 HOSE AS | 1 | |
| 2158029 | 9 HOSE AS | 1 | |
| 1P4577 | 10 FLANGE-HALF | 6 | |
| 1P4579 | 11 FLANGE-HALF | 12 | |
| 4D7388 | 12 CLIP | 2 | |
| 4J4382 | 13 PLUG-PIPE (1/2-14-THD) | 1 | |
| 5P1076 | 14 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P2566 | 15 BOLT (1/2-13X1.5-IN) | 20 | |
| 6V8188 | 16 NUT (1/2-13-THD) | 1 | |
| 7X0290 | 17 BOLT (3/8-16X3.5-IN) | 4 | |
| 7X0320 | 18 BOLT (7/16-14X5-IN) | 3 | |
| 8C4436 | 19 BOLT (1/2-13X1.375-IN) | 1 | |
| 8M4431 | 20 SEAL | 1 | |
| 8M4987 | 21 SEAL-O-RING | 5 | |
| 8M5010 | 22 SEAL-O-RING | 1 | |
| 8M5661 | 23 SEAL-O-RING | 6 | |
| 8M8281 | 24 SEAL-O-RING | 1 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8T4896 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 8T5360 | 27 WASHER (12X22.5X2.5-MM THK) | 3 | |
| 8T9389 | 28 BOLT (1/2-13X2.75-IN) | 4 | |
| 9B7237 | 29 BOLT (3/8-16X1.25-IN) | 10 | |
| 9D6196 | 30 CLIP (SLOT) | 1 | |
| 9D6197 | 31 CLIP (TAB) | 1 | |
| 9M7539 | 32 SEAL-O-RING | 1 |
