System And Components
7S-2983 PUMP GP-TRANSMISSIONS/N CWK1-UP; DRX1-UP
Group No: 7S-2983
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S5632 | 1 BODY AS-OIL PUMP | 1 | |
| 8M8489 | 2 DOWEL | 4 | |
| 1S6457 | 3 BODY AS-OIL PUMP | 1 | |
| 8M8489 | 4 DOWEL | 4 | |
| 7S2981 | 5 MANIFOLD AS-PUMP | 1 | |
| 9M0669 | 6 DOWEL | 2 | |
| 5M3320 | 7 BUSHING | 2 | |
| 8S3442 | 8 GEAR AS-PUMP (12-TEETH)(DRIVE) | 1 | |
| 8S3443 | 9 GEAR AS-PUMP (12-TEETH)(IDLER) | 1 | |
| 8S9169 | 10 MANIFOLD AS-PUMP | 1 | |
| 1M3909 | 11 BUSHING | 2 | |
| 1D4706 | 12 BOLT (3/8-16X6-IN) | 2 | |
| 5F4899 | 13 BOLT (3/8-16X5.5-IN) | 4 | |
| 3S0004 | 14 WASHER (0.406X0.728X0.09-IN THK) | 6 | |
| 8M5007 | 15 SEAL-O-RING | 4 | |
| 8S6237 | 16 GEAR (12-TEETH) | 2 | |
| 5M7908 | 17 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3S4327 | 18 COVER-OIL PUMP | 1 | |
| 1B8736 | 19 KEY-WOODRUFF | 1 | |
| 9S1018 | 20 WASHER (9.73X19.05X0.84-MM THK) | 4 | |
| 9S4182 | 21 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 22 SEAL-O-RING | 1 |
