System And Components
198-2806 TORQUE CONVERTER GPS/N CJY1-UP
Group No: 198-2806
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S2944 | 1 HOUSING AS | 1 | |
| 5M7937 | DOWEL | 6 | |
| 8S9094 | PLUG-ORIFICE | 1 | |
| 2152548 | 2 HOUSING-ROTATING | 1 | |
| 1T1993 | 3 WHEEL-TURBINE | 1 | |
| 4H1440 | 4 PIN-SPRING | 6 | |
| 1T2069 | 5 CARRIER-BEARING | 1 | |
| 1T0387 | 6 WHEEL-IMPELLER | 1 | |
| 2H9192 | 7 BALL BEARING | 1 | |
| 1T0839 | 8 GEAR-PUMP DRIVE (55-TEETH) | 1 | |
| 1T0844 | 9 CARRIER AS | 1 | |
| 1T0063 | SLEEVE-CARRIER | 1 | |
| 1T0968 | 10 RACE-BEARING OUTER | 1 | |
| 5H5312 | 11 BEARING-INNER | 1 | |
| 1982805 | 12 SHAFT-OUTPUT | 1 | |
| 1T1341 | 13 RING-SEAL | 2 | |
| 1T0069 | 14 RING-METAL SEAL | 1 | |
| 1T0417 | 15 BOLT-12 POINT HEAD (3/8-24X1-IN) | 8 | |
| 4B3388 | 16 BOLT (5/16-18X1.125-IN) | 36 | |
| 1T0738 | 17 WASHER (8.4X19X1.83-MM THK) | 36 | |
| 1T0414 | 18 BOLT-12 POINT HEAD (5/16-18X1-IN) | 8 | |
| 3F3727 | 19 RING-SNAP | 1 | |
| 1T2052 | 20 STATOR AS | 1 | |
| 1T0076 | 21 SPACER-BEARING | 1 | |
| 9P4253 | 22 DISC-FRICTION | 1 | |
| 0S1591 | 23 BOLT (3/8-16X1.5-IN) | 16 | |
| 8M3175 | 24 WASHER-HARD (10.2X16X3-MM THK) | 16 | |
| 3S1281 | 25 RING-SEAL | 1 | |
| 5S3586 | 26 PISTON-CLUTCH | 1 | |
| 8S3370 | 27 RING-SEAL | 1 | |
| 5S3579 | 28 GEAR-COUPLING (62-TEETH) | 1 | |
| 1T0822 | 29 BOLT-12 POINT HEAD (3/8-16X0.75-IN) | 6 | |
| 1T0846 | 30 RETAINER-BEARING | 1 | |
| 1T0532 | 31 BALL BEARING | 1 | |
| 2K0723 | 32 RING-RETAINING | 1 | |
| 2A4639 | 33 BOLT (3/8-16X1.625-IN) | 2 | |
| 8S6247 | 34 RETAINER-SHAFT | 1 | |
| 1M3937 | 35 RING-METAL SEAL | 2 |
