System And Components
215-2551 TORQUE CONVERTER GPS/N TCH1-UP
Group No: 215-2551
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8S6245 | 1 GEAR-COUPLING | 1 | |
| 2152548 | 2 HOUSING-ROTATING | 1 | |
| 1T1993 | 3 WHEEL-TURBINE | 1 | |
| 4H1440 | 4 PIN-SPRING | 6 | |
| 1T2069 | 5 CARRIER-BEARING | 1 | |
| 1T0387 | 6 WHEEL-IMPELLER | 1 | |
| 2H9192 | 7 BALL BEARING | 1 | |
| 1T0839 | 8 GEAR-PUMP DRIVE (55-TEETH) | 1 | |
| 1T0844 | 9 CARRIER AS | 1 | |
| 1T0063 | SLEEVE-CARRIER | 1 | |
| 1T0968 | 10 RACE-BEARING OUTER | 1 | |
| 5H5312 | 11 BEARING-INNER | 1 | |
| 2152553 | 12 SHAFT-OUTPUT | 1 | |
| 5H6199 | 13 RING-RETAINING | 1 | |
| 1T1341 | 14 RING-SEAL | 1 | |
| 1T0069 | 15 RING-METAL SEAL | 1 | |
| 1T0417 | 16 BOLT-12 POINT HEAD (3/8-24X1-IN) | 8 | |
| 4B3388 | 17 BOLT (5/16-18X1.125-IN) | 36 | |
| 1T0738 | 18 WASHER (8.4X19X1.83-MM THK) | 36 | |
| 1T0414 | 19 BOLT-12 POINT HEAD (5/16-18X1-IN) | 8 | |
| 3F3727 | 20 RING-SNAP | 1 | |
| 1T2052 | 21 STATOR AS | 1 | |
| 1T0076 | 22 SPACER-BEARING | 1 | |
| 1653929 | 23 BOLT (3/8-16X1.5-IN) | 16 | |
| 8M3175 | 24 WASHER-HARD (10.2X16X3-MM THK) | 16 | |
| 1T0822 | 25 BOLT-12 POINT HEAD (3/8-16X0.75-IN) | 6 | |
| 1T0846 | 26 RETAINER-BEARING | 1 | |
| 1T0532 | 27 BALL BEARING | 1 | |
| 1T0531 | 28 RETAINER | 1 | |
| 0S1584 | 29 BOLT (1/2-20X1.75-IN) | 1 | |
| 7M5130 | 30 PIN-SPRING | 1 |
