System And Components
164-4215 VALVE GP-RETARDER HYD CONTROLS/N CEZ1-UP
Group No: 164-4215
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S2121 | 1 PLUNGER | 1 | |
| 1S5567 | 2 COVER | 1 | |
| 1S5646 | 3 SPRING | 1 | |
| 2P9168 | 4 BODY-CONTROL VALVE | 1 | |
| 2S6538 | 5 SPRING | 1 | |
| 2S6547 | 6 STOP | 1 | |
| 4N8626 | 7 RACE-THRUST BEARING | 2 | |
| 5L1100 | 8 BEARING-THRUST | 1 | |
| 5S4498 | 9 SLUG | 1 | |
| 6P8601 | 10 STOP-RETARDER VALVE | 1 | |
| 7C0725 | 11 COVER | 1 | |
| 9H2367 | 12 SPRING-VALVE | 1 | |
| 9M7539 | 13 SEAL-O-RING | 1 | |
| 9S4684 | 14 PLUG | 1 | |
| 1541684 | 15 RETAINER | 1 | |
| 1541907 | 16 SPOOL | 1 | |
| 1580507 | 17 DIAPHRAGM | 1 | |
| 0S1588 | 19 BOLT (3/8-16X1.25-IN) | 4 | |
| 1T0414 | 20 BOLT-12 POINT HEAD (5/16-18X1-IN) | 1 | |
| 3J1907 | 21 SEAL-O-RING | 1 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8L6565 | 23 PIN-SPRING | 1 | |
| 8T6763 | 24 PLUG-PIPE (1/4-18-THD) | 1 | |
| 0S1591 | 25 BOLT (3/8-16X1.5-IN) | 4 |
