207-1876 GUARD GP-SCRAPER LINESS/N CEZ1-UP

Group No: 207-1876
Part NumberPart NameQty
8W07701 GUARD AS (RH)1
8W07732 GUARD AS (LH)1
8W29413 GUARD AS (LH)1
8W29424 GUARD AS (RH)1
8W92955 COVER AS (LH)1
1F0748NUT-WELD (1/2-13-THD)3
8W93236 COVER AS (RH)1
1F0748NUT-WELD (1/2-13-THD)3
8W93447 COVER AS2
1F0748NUT-WELD (1/2-13-THD)5
8W93868 GUARD (LH)1
8W93859 GUARD (RH)1
8X029410 PLATE AS (RH)1
8X029611 COVER AS2
1F0748NUT-WELD (1/2-13-THD)3
8X029912 PLATE AS (LH)1
376216513 GUARD1
376216614 GUARD (RH)1
160504115 GUARD AS (LH)1
1F0750NUT-WELD (3/8-16-THD)2
160504416 GUARD AS (RH)1
1F0750NUT-WELD (3/8-16-THD)2
206312917 CLAMP AS (LH)10
231454418 PLATE AS1
246233819 CLAMP AS (RH)10
4L645420 BOLT (3/8-16X1-IN)18
5P107521 WASHER-HARD (10.2X22.5X3-MM THK)8
5P107622 WASHER-HARD (13.5X30X4-MM THK)62
8T938423 BOLT (1/2-13X0.875-IN)38
7X036524 BOLT (3/4-10X1.5-IN)2
8T489625 WASHER-HARD (10.2X18.5X2.5-MM THK)10
8T499426 WASHER-HARD (20X36.5X3.5-MM THK)2
8T891727 BOLT (1/2-13X1.25-IN)24
