System And Components
4T-3751 LINES GP-EJECTORS/N CEZ1-399
Group No: 4T-3751
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8X3363 | 1 TUBE AS | 1 | |
| 4L6454 | 2 BOLT (3/8-16X1-IN) | 18 | |
| 5P1075 | 3 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 5B9627 | 4 WASHER (10.3X19X5-MM THK) | 4 | |
| 8X3733 | 5 CLAMP AS (RH) | 2 | |
| 8X3735 | CLAMP AS (LH) | 2 | |
| 7X0291 | 6 BOLT (3/8-16X3.75-IN) | 4 | |
| 8T4896 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 7X0365 | 8 BOLT (3/4-10X1.5-IN) | 2 | |
| 8T4994 | WASHER-HARD (20X36.5X3.5-MM THK) | 2 | |
| 8X3384 | 9 PLATE AS | 1 | |
| 1P4579 | 10 FLANGE-HALF | 4 | |
| 5P2566 | BOLT (1/2-13X1.5-IN) | 8 | |
| 4J0524 | SEAL-O-RING | 2 | |
| 8T4223 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8W1527 | 12 GUARD | 1 | |
| 8X3687 | 13 GUARD AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 8X3362 | 14 TUBE AS | 2 | |
| 1P4578 | 15 FLANGE-HALF | 8 | |
| 7X0308 | BOLT (7/16-14X1.375-IN) | 16 | |
| 8T5360 | WASHER (12X22.5X2.5-MM THK) | 16 | |
| 4J0522 | SEAL-O-RING | 4 | |
| 8J7783 | 16 HOSE AS | 1 | |
| 8X3294 | 17 HOSE AS | 1 | |
| 8X3686 | 18 GUARD AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 8W1528 | 19 GUARD | 1 | |
| 8T8917 | 20 BOLT (1/2-13X1.25-IN) | 4 | |
| 5P1076 | 21 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 4T2186 | 22 PLATE | 2 | |
| 8X1141 | 23 CLAMP | 4 | |
| 1S1445 | 24 PLATE | 2 | |
| 8X1147 | 25 SPACER (10.3X15.9X74.7-MM THK) | 4 | |
| 8T9378 | BOLT (3/8-16X4-IN) | 4 | |
| 6V8801 | NUT (3/8-16-THD) | 4 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 7X0331 | 27 BOLT (1/2-13X4.25-IN) | 2 | |
| 8X3388 | 28 CLAMP | 4 | |
| 7X0326 | 29 BOLT (1/2-13X3-IN) | 4 | |
| 1P3705 | SEAL-RECTANGULAR | 1 | |
| 8X3387 | 30 CLAMP | 2 | |
| 7X0325 | 31 BOLT (1/2-13X2.5-IN) | 4 | |
| 8W9385 | 32 GUARD (RH) | 1 | |
| 8W9386 | GUARD (LH) | 1 | |
| 8T8917 | 33 BOLT (1/2-13X1.25-IN) | 32 | |
| 5P1076 | 34 WASHER-HARD (13.5X30X4-MM THK) | 54 | |
| 8W9295 | 35 COVER AS (LH) | 2 | |
| 8W9323 | COVER AS (RH) | 2 | |
| 8X0296 | 36 COVER AS | 2 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 3 | |
| 8W2397 | 37 HOSE AS | 2 | |
| 4J0522 | SEAL-O-RING | 2 | |
| 8X0294 | 38 PLATE AS (RH) | 1 | |
| 8X0299 | PLATE AS (LH) | 1 | |
| 7J8471 | BLOCK | 1 | |
| 8W0770 | 39 GUARD AS | 1 | |
| 8W0773 | GUARD AS | 1 | |
| 8X3733 | 40 CLAMP AS (RH) | 8 | |
| 8X3735 | CLAMP AS | 8 | |
| 8T9384 | 41 BOLT (1/2-13X0.875-IN) | 4 | |
| 8W2942 | 42 GUARD AS (RH) | 1 | |
| 8W2941 | GUARD AS (LH) | 1 | |
| 7X0290 | 43 BOLT (3/8-16X3.5-IN) | 16 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 8X2768 | 44 BOLT (1/2-13X1.22-IN) | 8 | |
| 5P2228 | 45 BOLT (1/2-13X1-IN) | 14 |
