System And Components
4T-3751 LINES GP-EJECTORS/N CEZ400-UP
Group No: 4T-3751
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4T2186 | 1 PLATE | 2 | |
| 5B9627 | 2 WASHER (10.3X19X5-MM THK) | 4 | |
| 8J7783 | 3 HOSE AS | 1 | |
| 8X1141 | 4 CLAMP | 4 | |
| 8X1147 | 5 SPACER (10.3X15.9X74.7-MM THK) | 4 | |
| 8X3362 | 7 TUBE AS | 2 | |
| 8X3363 | 8 TUBE AS | 1 | |
| 8X3388 | 10 CLAMP | 4 | |
| 2318043 | 11 HOSE AS | 1 | |
| 2357100 | 12 HOSE AS | 2 | |
| 1P3705 | 13 SEAL-RECTANGULAR | 1 | |
| 1P4578 | 14 FLANGE-HALF | 8 | |
| 1P4579 | 15 FLANGE-HALF | 4 | |
| 1S1445 | 16 PLATE | 2 | |
| 4J0522 | 17 SEAL-O-RING | 6 | |
| 4J0524 | 18 SEAL-O-RING | 2 | |
| 4L6454 | 19 BOLT (3/8-16X1-IN) | 18 | |
| 4L9337 | 20 BOLT (3/8-16X1.5-IN) | 1 | |
| 5P1075 | 21 WASHER-HARD (10.2X22.5X3-MM THK) | 40 | |
| 5P1076 | 22 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P2566 | 24 BOLT (1/2-13X1.5-IN) | 8 | |
| 6V1572 | 25 CLIP (SLOT) | 1 | |
| 6V1573 | 26 CLIP (TAB) | 1 | |
| 6V1875 | 27 GROMMET | 1 | |
| 6V8801 | 28 NUT (3/8-16-THD) | 5 | |
| 7X0290 | 29 BOLT (3/8-16X3.5-IN) | 16 | |
| 7X0308 | 30 BOLT (7/16-14X1.375-IN) | 16 | |
| 7X0325 | 31 BOLT (1/2-13X2.5-IN) | 4 | |
| 7X0326 | 32 BOLT (1/2-13X3-IN) | 4 | |
| 7X0331 | 33 BOLT (1/2-13X4.25-IN) | 2 | |
| 7X0365 | 34 BOLT (3/4-10X1.5-IN) | 2 | |
| 8T4223 | 35 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 8T4896 | 36 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T4994 | 37 WASHER-HARD (20X36.5X3.5-MM THK) | 2 | |
| 8T5360 | 38 WASHER (12X22.5X2.5-MM THK) | 16 | |
| 8T8917 | 39 BOLT (1/2-13X1.25-IN) | 4 | |
| 8T9378 | 40 BOLT (3/8-16X4-IN) | 8 |
