System And Components
125-8277 LINES GP-ENGINE OILS/N 5XD1233-UP
Group No: 125-8277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1591 | 1 BOLT (3/8-16X1.5-IN) | 1 | |
| 3B1915 | 2 BOLT (3/8-16X1.375-IN) | 1 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1232894 | 4 SUPPORT-SUCTION LINE | 1 | |
| 8N2104 | 5 BELL AS-SUCTION | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 4N0913 | 6 SCREEN-STRAINER (ENGINE OIL) | 1 | |
| 4N0914 | 7 CLIP | 1 | |
| 1160765 | 8 TUBE AS-OIL PUMP | 1 | |
| 0L1351 | 9 BOLT (3/8-16X0.875-IN) | 1 | |
| 8M9024 | 10 WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 0S1571 | 11 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 2 | |
| 1162700 | 13 TUBE AS | 1 | |
| 1090078 | 14 SEAL-O-RING | 1 | |
| 1090076 | 15 SEAL-O-RING | 1 |
