System And Components
188-3102 LINES GP-FILTERS/N 5XD1233-4473
Group No: 188-3102
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N8600 | 1 ADAPTER-BASE | 1 | |
| 2P4305 | 2 GASKET | 2 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 8 | |
| 7C9010 | 5 SUPPORT-BASE | 1 | |
| 0S1571 | 6 BOLT (3/8-16X1.75-IN) | 5 | |
| 9S8752 | 7 NUT-FULL (3/8-16-THD) | 5 | |
| 1238188 | 8 BRACKET AS-FILTER | 1 | |
| 1A1460 | 9 BOLT (1/2-13X2-IN) | 1 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 12 | |
| 3P0650 | 12 SEAL-O-RING | 3 | |
| 1W1116 | 13 BODY-BYPASS | 1 | |
| 0L2070 | 14 BOLT (3/8-16X2.25-IN) | 1 | |
| 0617540 | 15 SEAL-O-RING | 4 | |
| 5P8068 | 16 SEAL-O-RING | 1 | |
| 1P4578 | 17 FLANGE-HALF | 8 | |
| 5P8244 | 18 WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 6K3771 | 19 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 16 | |
| 5P9890 | 20 SEAL-O-RING | 2 | |
| 1190960 | 21 BRACKET | 1 | |
| 1254390 | 22 HOSE AS | 2 | |
| 0S1608 | 23 BOLT (3/8-16X3.75-IN) | 1 | |
| 0T0065 | 24 BOLT (3/8-16X3.5-IN) | 1 | |
| 6V5048 | 25 SEAL-O-RING | 1 | |
| 8C3446 | 26 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 8C3445 | 27 CAP-DUST (FLUID SAMPLING)(ENGINE OIL) | 1 | |
| 7D1649 | 28 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 1F7958 | 29 NUT-FULL (1/2-13-THD) | 1 | |
| 0S1595 | 30 BOLT (1/2-13X1.25-IN) | 1 | |
| 1P1367 | 31 PLUNGER (RELIEF VALVE) | 2 | |
| 9F6304 | 32 SPRING | 2 | |
| 4N0861 | 33 COVER | 1 | |
| 4N0865 | 34 GASKET | 1 | |
| 4N8410 | 35 TUBE-COOLER BYPASS | 1 | |
| 4N8770 | 36 ELBOW-COOLER OUTLET | 1 | |
| 9X6458 | 37 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
