176-6619 LINES GP-AIRS/N 5XD1233-UP

Group No: 176-6619

Part Number	Part Name	Qty
1W6186	1 SHIELD AS	1
6V5044	NUT-WELD (5/16-18-THD)	2
2W4715	2 PLATE	1
4K8657	3 ANGLE	1
4N1779	4 COVER	1
4N1848	5 GASKET	1
4N4307	6 GASKET	1
4N7248	7 PLATE	1
4W4314	8 SUPPORT-TURBOCHARGER	1
6N2331	9 GASKET	1
7E3205	10 MANIFOLD-INLET	1
7W8110	11 SUPPORT AS	1
8N0879	12 CLAMP	4
8N2258	13 SHIELD AS-BOTTOM	1
6V5044	NUT-WELD (5/16-18-THD)	7
9M4136	SPACER (0.438X0.75X0.5-IN THK)	5
9N1081	14 ADAPTER-TRANSFER PIPE	1
1078618	15 SENSOR GP-TEMPERATURE (INLET AIR)	1
1028803	KIT-RECEPTACLE (3-PIN)(AIR INLET TEMPERATURE SENSOR)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	1
1124550	SLEEVE
6V3582	16 CLAMP-HOSE	6
1743999	17 SUPPORT-AIR CLEANER	1
1755512	18 BRACKET AS	1
8T5912	NUT-WELD (3/8-16-THD)	1
1755515	19 ELBOW	1
1773242	20 PLATE	1
2260143	21 TUBE AS	1
2260144	22 TUBE AS	1
2263861	23 SHIELD AS-HEAT	1
2263862	24 SHIELD AS-HEAT	1
0L1143	25 BOLT (3/8-16X2.5-IN)	1
0L1351	26 BOLT (3/8-16X0.875-IN)	3
0L1352	27 BOLT (3/8-16X3.25-IN)	3
0L2070	28 BOLT (3/8-16X2.25-IN)	3
0S0509	29 BOLT (3/8-16X0.75-IN)	1
0S1571	30 BOLT (3/8-16X1.75-IN)	4
0S1588	31 BOLT (3/8-16X1.25-IN)	3
0S1590	32 BOLT (3/8-16X2-IN)	1
0S1591	33 BOLT (3/8-16X1.5-IN)	2
0S1594	34 BOLT (3/8-16X1-IN)	8
0S1608	35 BOLT (3/8-16X3.75-IN)	2
1A2029	36 BOLT (3/8-16X1.125-IN)	6
5B7890	37 PLUG-PIPE	2
5M2894	38 WASHER-HARD (10.2X18.5X2.5-MM THK)	36
5P2755	39 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN)	4
5P9959	40 BOLT (5/16-18X0.5-IN)	2
5S1188	41 SEAL-O-RING	2
8L2786	42 SEAL-O-RING	1
8T6765	43 PLUG-PIPE (1/4-18-THD)	3
9F8596	44 LUG	1
9M1974	45 WASHER-HARD (8.8X16X2-MM THK)	2
9S8752	46 NUT-FULL (3/8-16-THD)	11
9X6458	47 WASHER-HARD (10.2X22.5X3-MM THK)	4
