System And Components
234-6731 SHIELD GP-MANIFOLDS/N CEH1-UP
Group No: 234-6731
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W0467 | 1 PLATE | 1 | |
| 1W6185 | 2 SHIELD AS | 1 | |
| 4P0692 | 3 CLAMP AS | 2 | |
| 7C2199 | CLAMP | 1 | |
| 1081434 | GROMMET | 1 | |
| 8N1594 | 4 SHIELD AS | 2 | |
| 8N1619 | 5 SHIELD AS | 2 | |
| 8N2368 | 6 SHIELD AS | 1 | |
| 8N7953 | 7 PLATE | 1 | |
| 8N7954 | 8 PLATE | 2 | |
| 1135421 | 9 PLATE | 2 | |
| 1140915 | 10 SHIELD AS (MANIFOLD) | 1 | |
| 1140917 | 11 SHIELD AS | 2 | |
| 1265056 | 12 SHIELD AS-MANIFOLD | 1 | |
| 1265057 | 13 SHIELD AS-MANIFOLD | 1 | |
| 1A7462 | 14 STUD | 8 | |
| 2P0911 | 15 ANGLE | 1 | |
| 4L6454 | 16 BOLT (3/8-16X1-IN) | 9 | |
| 4L6459 | 17 BOLT (3/8-16X2.5-IN) | 1 | |
| 4M6425 | 18 BOLT (5/16-18X1-IN) | 2 | |
| 5K0906 | 19 BOLT (5/16-18X0.625-IN) | 13 | |
| 5P1075 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 7 | |
| 5P1076 | 21 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P4116 | 22 WASHER-HARD (8.8X20.5X2-MM THK) | 22 | |
| 6V2712 | 23 STUD | 4 | |
| 6V8189 | 24 NUT (5/16-18-THD) | 20 | |
| 6V8801 | 25 NUT (3/8-16-THD) | 3 | |
| 7V2400 | 26 STRIP | 2 | |
| 8J4110 | 27 CLAMP | 2 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 22 | |
| 8T4896 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 8T5391 | 30 BOLT (5/16-18X0.5-IN) | 9 | |
| 8T8919 | 31 BOLT (1/2-13X1.75-IN) | 2 | |
| 9B7237 | 32 BOLT (3/8-16X1.25-IN) | 3 |
