Assembly
100%

137-1705 GUARD GP-BELTS/N TAM1-UP

Group No: 137-1705
Part NumberPart NameQty
7E97851 GUARD AS1
1F0750NUT-WELD (3/8-16-THD)1
4K9097NUT-WELD (5/16-18-THD)5
7E97872 COVER AS-DAMPER1
4K9097NUT-WELD (5/16-18-THD)3
7E97923 COVER AS1
4K9097NUT-WELD (5/16-18-THD)1
13717124 COVER AS1
13717105 SHROUD AS1
13717116 SHROUD AS1
7E97897 SPACER AS1
7E97918 PLATE1
7E97909 SUPPORT1
8T904310 BOLT (5/16-18X0.875-IN)5
8T422411 WASHER-HARD (8.8X16X2-MM THK)7
5S737912 BOLT (3/8-16X0.875-IN)7
8T489613 WASHER-HARD (10.2X18.5X2.5-MM THK)12
1S483614 SPACER (0.438X0.75X2.12-IN THK)1
7X029015 BOLT (3/8-16X3.5-IN)1
5S738316 BOLT (3/8-16X1.75-IN)2
6V880117 NUT (3/8-16-THD)2
5K090618 BOLT (5/16-18X0.625-IN)2
