System And Components
3N-7714 PUMP GP-AUXILIARY SEA WATERS/N TAM1-UP
Group No: 3N-7714
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3N8220 | 1 CLAMP AS | 1 | |
| 3N8211 | 2 SPACER (30.62X40X16.75-MM THK) | 1 | |
| 3N8221 | 3 CLAMP AS | 2 | |
| 3N8202 | 4 BODY-PUMP | 1 | |
| 5H3204 | 5 LOCK (T-SHAPED) | 3 | |
| 6V8801 | 6 NUT (3/8-16-THD) | 3 | |
| 9L1321 | 7 STUD-TAPERLOCK (3/8-16X1.18-IN) | 3 | |
| 2H5549 | 8 RING-RETAINING (INTERNAL) | 1 | |
| 2H3829 | 9 RACE-BEARING INNER | 1 | |
| 5M9644 | 10 BEARING-OUTER | 1 | |
| 3N8204 | 11 HOUSING-BEARING | 1 | |
| 2L5271 | 12 BALL BEARING | 1 | |
| 4L9020 | 13 RING-RETAINING (EXTERNAL) | 1 | |
| 3N8203 | 14 SHAFT-DRIVE | 1 | |
| 2H3776 | 15 LOCKNUT | 1 | |
| 2H3779 | 16 LOCK | 1 | |
| 5N2905 | 17 COLLAR-SEAL | 1 | |
| 5N2903 | 18 SEAL-OIL | 1 | |
| 3N8208 | 19 THROWER-WATER | 1 | |
| 1974727 | 21 SEAL AS | 1 | |
| 3N8217 | 22 SHIM (0.25-MM THK) | 2 | |
| 3N8218 | 23 SHIM (0.38-MM THK) | 2 | |
| 3N8214 | 24 IMPELLER | 1 | |
| 3N8201 | 25 SEAL-O-RING | 1 | |
| 3N8213 | 26 RING | 1 | |
| 1041718 | 27 PLUG | 1 | |
| 3N8215 | 28 WASHER | 1 | |
| 5N4503 | 29 PLATE-PORT | 2 | |
| 7X2651 | 30 NUT-FULL | 1 | |
| 1487992 | 31 KEY | 1 | |
| 3B4618 | 32 PIN-COTTER | 1 | |
| 1494312 | 33 WASHER (17X30X3.5-MM THK) | 1 | |
| 3N8198 | 34 BODY-PUMP | 1 |
