System And Components
3N-8561 PUMP GP-AUXILIARY SEA WATERS/N TAM1-UP
Group No: 3N-8561
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C3613 | 1 PUMP GP-AUXILIARY SEA WATER | 1 | |
| 3N8769 | 2 ELBOW | 1 | |
| 8B6283 | 3 GASKET | 2 | |
| 4L9337 | 4 BOLT (3/8-16X1.5-IN) | 8 | |
| 6V8801 | 5 NUT (3/8-16-THD) | 13 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 3N8415 | 6 FLANGE | 2 | |
| 3S1889 | GASKET | 2 | |
| 5L5879 | 7 ADAPTER AS | 1 | |
| 5B3265 | GASKET | 1 | |
| 8T6766 | 8 PLUG-PIPE | 1 | |
| 6L2280 | 9 ROD-ZINC (AUXILIARY SEA WATER PUMP) | 1 | |
| 6L2279 | PLUG-PIPE | 1 | |
| 3N8410 | 10 ELBOW-WATER PUMP | 1 | |
| 5K9243 | 11 ELBOW-FLARED | 2 | |
| 8T2501 | 12 BOLT (3/8-16X2-IN) | 1 | |
| 5S6981 | RETAINER | 1 | |
| 7W5648 | 13 GASKET | 1 | |
| 5N2504 | 14 GEAR (43-TEETH) | 1 | |
| 3N8435 | 15 TUBE AS-LUBRICATION | 1 | |
| 6H4746 | 16 ADAPTER | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 3N8401 | 17 ADAPTER-PUMP MOUNTING | 1 | |
| 5P7972 | 18 BOLT-12 POINT HEAD (7/16-14X1.75-IN) | 4 | |
| 7X0447 | NUT (7/16-14-THD) | 4 | |
| 8T5360 | WASHER (12X22.5X2.5-MM THK) | 4 | |
| 2H3934 | 19 SEAL-O-RING | 1 |
