System And Components
7C-3613 PUMP GP-AUXILIARY SEA WATERS/N TAM1-UP
Group No: 7C-3613
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N6055 | 1 SEAL GP | 1 | |
| 3N8448 | 2 BODY-DRIVE END | 1 | |
| 1075565 | 3 CLIP | 1 | |
| 3N8447 | 4 BODY-DRIVE END | 1 | |
| 3N8468 | 5 CLAMP AS | 2 | |
| 1B9575 | BOLT (5/16-18X1.56-IN) | 2 | |
| 5S0003 | NUT (5/16-18-THD) | 2 | |
| 4P9312 | 6 PIN-COTTER | 1 | |
| 1074910 | 7 BOLT-HIGH TEMPERATURE (7/16-14X1-IN) | 4 | |
| 3B4507 | LOCKWASHER | 4 | |
| 1J6472 | 8 RING-RETAINING | 1 | |
| 6I2092 | 9 HOUSING-BEARING | 1 | |
| 7X2652 | 10 NUT-SLOTTED | 1 | |
| 3N8446 | WASHER (21X37X3.3-MM THK) | 1 | |
| 7C3493 | 11 SHAFT | 1 | |
| 8B7614 | 12 NUT-BEARING | 1 | |
| 8B7613 | 13 LOCKNUT | 1 | |
| 3N8445 | 14 SPACER (40.041X47X12-MM THK) | 1 | |
| 1756716 | 15 KEY | 1 | |
| 3N8463 | 16 BEARING-ROLLER | 1 | |
| 4M6107 | 17 BEARING-INNER | 1 | |
| 8T0209 | RACE-ROLLER BEARING | 1 | |
| 5N2904 | 18 COLLAR-SEAL | 1 | |
| 5N2902 | 19 SEAL-OIL | 1 | |
| 3N8442 | 20 SPACER-SPECIAL | 1 | |
| 3N8462 | 21 SEAL-O-RING | 1 | |
| 3N8469 | 22 CLAMP AS | 1 | |
| 1D4716 | NUT-FULL (5/16-18-THD) | ||
| 1D4540 | BOLT (5/16-18X2.75-IN) | 2 | |
| 3N8452 | 23 RING | 1 | |
| 3N8449 | 24 IMPELLER | 1 | |
| 1041718 | 25 PLUG | 1 | |
| 5N4504 | 26 PLATE-PORT | 2 | |
| 3N8441 | 27 SHIM (0.38-MM THK) | 2 | |
| 3N8455 | SHIM (0.25-MM THK) | 2 | |
| 1302366 | SHIM (0.3-MM THK) | 1 |
