System And Components
6N-2992 TANK GP-EXPANSIONS/N TAM1-UP
Group No: 6N-2992
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N6945 | 1 TUBE AS | 1 | |
| 2N1287 | 2 ELBOW-FLARED | 1 | |
| 1090075 | 3 SEAL-O-RING | 2 | |
| 0L1143 | 4 BOLT (3/8-16X2.5-IN) | 4 | |
| 7C0307 | 5 GASKET (REGULATOR HOUSING, OUTLET) | 4 | |
| 7N3179 | 6 ELBOW | 1 | |
| 8N7779 | 7 COVER AS-HOUSING | 2 | |
| 4M1336 | 7A FERRULE | 1 | |
| 3S9643 | 7B SEAL-LIP TYPE (WATER TEMPERATURE REGULATOR) | 1 | |
| 0S1608 | 10 BOLT (3/8-16X3.75-IN) | 6 | |
| 7N0468 | 11 TUBE AS | 1 | |
| 8S9089 | 12 BOLT (1/2-13X4.5-IN) | 2 | |
| 8N7446 | 13 SUPPORT-EXPANSION TANK | 2 | |
| 8T6764 | 14 PLUG-PIPE (1/8-27-THD) | 1 | |
| 2B0947 | 15 BOLT (1/2-13X2.25-IN) | 4 | |
| 2M0849 | 16 WASHER-HARD (13.5X25.5X5-MM THK) | 6 | |
| 0S1587 | 17 BOLT (1/2-13X1.75-IN) | 2 | |
| 4N9617 | 18 ELBOW | 1 | |
| 0L1352 | 19 BOLT (3/8-16X3.25-IN) | 2 | |
| 0S1590 | 20 BOLT (3/8-16X2-IN) | 2 | |
| 4N3858 | 21 GASKET (TEMPERATURE REGULATOR) | 2 | |
| 2485513 | 22 REGULATOR-WATER TEMPERATURE (92-DEG C)(COOLANT) | 2 | |
| 4N3964 | 23 ELBOW | 2 | |
| 0S1594 | 24 BOLT (3/8-16X1-IN) | 14 | |
| 4N9719 | 25 COVER | 2 | |
| 4L3862 | 26 GASKET | 4 | |
| 1A2029 | 27 BOLT (3/8-16X1.125-IN) | 6 | |
| 5M2894 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 | |
| 2N0931 | 29 GASKET | 3 | |
| 4N9598 | 30 ELBOW | 1 | |
| 8T6762 | 31 PLUG-PIPE (1/2-14-THD) | 4 | |
| 8N8002 | 32 ELBOW | 1 | |
| 6N2175 | 33 ELBOW | 1 | |
| 1107753 | 34 SEAL-O-RING | 2 | |
| 6N2176 | 35 PIPE | 1 | |
| 1090079 | 36 SEAL-O-RING | 2 | |
| 6N7222 | 37 ELBOW-WATER TRANSFER | 1 | |
| 4N8498 | 38 COVER-WATER PUMP | 1 | |
| 0S1588 | 39 BOLT (3/8-16X1.25-IN) | 16 | |
| 9S8752 | 40 NUT-FULL (3/8-16-THD) | 4 | |
| 4N9676 | 41 ELBOW-OUTLET | 1 | |
| 4N9699 | 42 PIPE | 1 | |
| 4N9720 | 43 FLANGE | 2 | |
| 8N8003 | 44 ELBOW | 1 | |
| 1107752 | 45 SEAL-O-RING | 4 | |
| 4N9639 | 46 COUPLING | 1 | |
| 7W0316 | 47 CLAMP | 2 | |
| 1088066 | 48 COUPLING | 1 | |
| 9S7695 | 49 TEE | 1 | |
| 7W0315 | 50 TANK AS-EXPANSION | 1 | |
| 5M6213 | PLUG-PIPE (1/4-18-THD) | 2 | |
| 5M6214 | PLUG (1/8-27 PTF) | 1 | |
| 9S5540 | LUG | 2 | |
| 8N9758 | 51 CLAMP | 2 | |
| 1L8212 | 52 GASKET | 1 | |
| 0S1594 | 53 BOLT (3/8-16X1-IN) | 6 | |
| 0L1352 | 54 BOLT (3/8-16X3.25-IN) | 2 | |
| 6N2688 | 55 ELBOW | 1 | |
| 9H2282 | 56 GASKET-STARTING MOTOR | 1 | |
| 8T6762 | 57 PLUG-PIPE (1/2-14-THD) | 1 | |
| 1A2029 | 58 BOLT (3/8-16X1.125-IN) | 3 | |
| 4N1156 | 59 GASKET-REGULATOR COVER (TEMPERATURE REGULATOR HOUSING) | 2 | |
| 8N6946 | 60 TUBE AS | 1 | |
| 3D2824 | 61 SEAL-O-RING | 1 | |
| 0L2070 | 62 BOLT (3/8-16X2.25-IN) | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9M4136 | 63 SPACER (0.438X0.75X0.5-IN THK) | 2 | |
| 8T6765 | 64 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S8752 | 65 NUT-FULL (3/8-16-THD) | 2 | |
| 0S1588 | 66 BOLT (3/8-16X1.25-IN) | 4 |
