System And Components
246-8413 AIR CLEANER GPS/N TAM1-UP
Group No: 246-8413
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P0600 | 1 CLAMP-HOSE | 2 | |
| 8T4988 | 2 CLAMP-HOSE | 3 | |
| 9X6654 | 3 CLAMP-HOSE | 3 | |
| 0965028 | 4 INDICATOR-AIR FILTER CHANGE | 1 | |
| 1131584 | 5 STRIP | 2 | |
| 2022173 | 6 HOSE | 1 | |
| 2049255 | 7 BRACKET | 1 | |
| 2058021 | 8 BRACKET | 1 | |
| 2410566 | 9 HOSE | 1 | |
| 2413917 | 10 BRACKET AS | 1 | |
| 2416592 | 11 TUBE | 1 | |
| 2435381 | 12 HOSE | 1 | |
| 2435605 | 13 HOSE | 1 | |
| 2436499 | 14 TUBE | 1 | |
| 2544293 | 15 CAP GP-AIR CLEANER | 1 | |
| 5P0600 | CLAMP-HOSE | 1 | |
| 2466087 | 16 AIR CLEANER GP | 1 | |
| 2467180 | 17 STRAP | 1 | |
| 1007749 | 18 U-BOLT | 2 | |
| 5S7379 | 19 BOLT (3/8-16X0.875-IN) | 4 | |
| 8T4196 | 20 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 2K4973 | 22 LOCKNUT (3/8-16-THD) | 4 | |
| 8T0389 | 23 LOCKNUT (M10X1.5-THD) | 2 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 8T7008 | 25 BOLT (3/8-16X3-IN) | 4 |
