System And Components
247-9632 AIR CLEANER GPS/N TAM1-UP
Group No: 247-9632
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4988 | 1 CLAMP-HOSE | 3 | |
| 9X6654 | 2 CLAMP-HOSE | 3 | |
| 0965028 | 3 INDICATOR-AIR FILTER CHANGE | 1 | |
| 1115145 | 4 CLAMP-HOSE | 2 | |
| 1131584 | 5 STRIP | 2 | |
| 2022173 | 6 HOSE | 1 | |
| 2049255 | 7 BRACKET | 1 | |
| 2058021 | 8 BRACKET | 1 | |
| 2410307 | 9 CLAMP | 1 | |
| 2410566 | 10 HOSE | 1 | |
| 2413918 | 11 BRACKET AS | 1 | |
| 2416593 | 12 TUBE | 1 | |
| 2430218 | 13 CAP AS-RAIN | 1 | |
| 2430897 | 14 AIR CLEANER GP | 1 | |
| 2435381 | 15 HOSE | 1 | |
| 2435606 | 16 HOSE | 1 | |
| 2436499 | 17 TUBE | 1 | |
| 1007749 | 18 U-BOLT | 2 | |
| 1313540 | 19 LOCKNUT (M8X1.25-THD) | 4 | |
| 5S7379 | 20 BOLT (3/8-16X0.875-IN) | 8 | |
| 2K4973 | 21 LOCKNUT (3/8-16-THD) | 4 | |
| 7X0818 | 22 BOLT (M8X1.25X45-MM) | 4 | |
| 8T4224 | 23 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 8T7008 | 25 BOLT (3/8-16X3-IN) | 2 |
