7C-9969 FASTENER GP-WIRING HARNESSS/N TAM1-UP

Group No: 7C-9969
Part NumberPart NameQty
9G91511 CLIP2
5M30622 BOLT (3/8-16X0.75-IN)1
8T48963 WASHER-HARD (10.2X18.5X2.5-MM THK)2
8M27734 CLIP (LOOP)3
9G91515 CLIP1
8C31216 BOLT (5/16-18X1.5-IN)3
8M27737 CLIP (LOOP)3
8T48968 WASHER-HARD (10.2X18.5X2.5-MM THK)8
8T70089 BOLT (3/8-16X3-IN)1
7C435410 CLIP2
4L933711 BOLT (3/8-16X1.5-IN)1
4L933712 BOLT (3/8-16X1.5-IN)3
7C435413 CLIP4
2W061914 WIRE AS1
5P411615 WASHER-HARD (8.8X20.5X2-MM THK)1
8C687616 BOLT (5/16-18X1.625-IN)1
3S209317 STRAP-CABLE8
5P411618 WASHER-HARD (8.8X20.5X2-MM THK)3
3S209319 STRAP-CABLE1
5M306220 BOLT (3/8-16X0.75-IN)1
5S737921 BOLT (3/8-16X0.875-IN)1
6V880122 NUT (3/8-16-THD)1
8T250123 BOLT (3/8-16X2-IN)1
3S718924 BRACKET1
9G915125 CLIP1
4S445526 CLIP5
7C435327 CLIP1
9B723728 BOLT (3/8-16X1.25-IN)2
8T489629 WASHER-HARD (10.2X18.5X2.5-MM THK)1
8T489630 WASHER-HARD (10.2X18.5X2.5-MM THK)7
6V880131 NUT (3/8-16-THD)1
6V880132 NUT (3/8-16-THD)2
3S209333 STRAP-CABLE2
8M277334 CLIP (LOOP)3
8M277335 CLIP (LOOP)3
5M306236 BOLT (3/8-16X0.75-IN)1
4L933737 BOLT (3/8-16X1.5-IN)1
8T250238 BOLT (3/8-16X1.125-IN)2
3S718939 BRACKET1
8L841340 STRAP-CABLE (WHITE)2
