System And Components
169-1846 MOUNTING GP-CIRCUIT BREAKERS/N 6DA4802-UP
Group No: 169-1846
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1691856 | 1 BRACKET | 1 | |
| 7W0909 | 2 BRACKET-MOUNTING | 1 | |
| 3N6734 | 3 NUT-SPRING (3/8-16-THD) | 4 | |
| 5P1075 | 4 WASHER-HARD (10.2X22.5X3-MM THK) | 29 | |
| 5M3062 | 5 BOLT (3/8-16X0.75-IN) | 4 | |
| 7K1181 | 6 STRAP-CABLE | 6 | |
| 4W7334 | 7 CABLE AS | 2 | |
| 6V8801 | 8 NUT (3/8-16-THD) | 14 | |
| 8T0192 | 9 BOLT (3/8-16X2.25-IN) | 4 | |
| 9B7237 | 10 BOLT (3/8-16X1.25-IN) | 3 | |
| 4W6393 | 11 FILM-TERMINAL STRIP | 1 | |
| 2S1647 | 12 GROMMET | 1 | |
| 8T5409 | 13 STUD-TAPERLOCK (3/8-16X1.57-IN) | 3 | |
| 4W7142 | 14 INSULATOR | 3 | |
| 5P8167 | 15 BOLT (3/8-16X0.625-IN) | 3 | |
| 4W7157 | 16 FILM-TERMINAL STRIP | 1 | |
| 7W0908 | 17 BRACKET-MOUNTING | 1 | |
| 5P2566 | 18 BOLT (1/2-13X1.5-IN) | 1 | |
| 5P1076 | 19 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V8188 | 20 NUT (1/2-13-THD) | 1 | |
| 5S7382 | 21 BOLT (3/8-16X1.375-IN) | 1 | |
| 8T2872 | 22 BOLT-FLANGE HEAD (3/8-16X1-IN) | 4 |
