System And Components
105-5081 STARTING MOTOR GP-AIRS/N TAM1-UP
Group No: 105-5081
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N4375 | 1 BALL BEARING | 1 | |
| 4N4377 | 2 PLATE-REAR END | 1 | |
| 4N4383 | 3 HOUSING-MOTOR | 1 | |
| 4N4379 | 4 DOWEL-CYLINDER | 1 | |
| 4N4390 | 5 WASHER-THRUST (0.797X1.50X0.125-IN THK) | 1 | |
| 4N4391 | 6 KEY-GEAR | 1 | |
| 4N4387 | 7 CASE AS-GEAR | 1 | |
| 4N4388 | 7A WASHER-SPECIAL | 1 | |
| 0091436 | 7B BEARING | 1 | |
| 4N4394 | 8 GEAR-DRIVE (45-TEETH) | 1 | |
| 5F8651 | 9 BALL BEARING | 1 | |
| 4N4392 | 10 COVER AS-CASE | 1 | |
| 4N4393 | 10A SEAL-LIP TYPE | 1 | |
| 6J2244 | 10B SEAL-O-RING | 1 | |
| 6V1179 | 10C SEAL-O-RING | 1 | |
| 4N4397 | 11 COLLAR-DRIVE SHAFT | 1 | |
| 1055136 | 12 WASHER (9.92X16.67X0.79-MM THK) | 4 | |
| 3P0653 | 13 SEAL-O-RING | 1 | |
| 4N4403 | 14 SPRING-RING | 1 | |
| 1055138 | 15 HOUSING | 1 | |
| 4N4405 | 16 CLUTCH AS-DRIVE | 1 | |
| 4N4421 | 17 SHAFT-DRIVE | 1 | |
| 1055137 | 18 PISTON | 1 | |
| 4N4400 | 19 RING-SHIFT | 2 | |
| 4N4402 | 20 SPACER (2.156X2.375X0.188-IN THK) | 1 | |
| 0520512 | 21 RING-RETAINING (INTERNAL) | 1 | |
| 4N4386 | 22 RETAINER-PINION | 1 | |
| 4N4413 | 23 PINION-ROTOR | 1 | |
| 9B9774 | 24 BALL BEARING | 1 | |
| 4N4384 | 25 GASKET-GEAR CASE | 1 | |
| 4N4382 | 26 PLATE-FRONT END | 1 | |
| 4N4378 | 27 CYLINDER | 1 | |
| 4N4381 | 28 ROTOR | 1 | |
| 4N4376 | 29 GASKET-HOUSING COVER | 1 | |
| 5L4035 | 30 RING-RETAINING (EXTERNAL) | 1 | |
| 8F8544 | 31 BOLT (3/8-16X6.25-IN) | 4 | |
| 7B2742 | 32 BOLT (1/4-20X1.25-IN) | 9 | |
| 5P0537 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 4N4409 | 34 DEFLECTOR AS (ROAD SPLASH) | 1 | |
| 8T6763 | 35 PLUG-PIPE (1/4-18-THD) | 2 | |
| 6D3787 | 36 BEARING-ROLLER | 1 | |
| 4N4380 | 37 KIT-VANE (AIR STARTING MOTOR) | 1 | |
| 4N4371 | 38 COVER AS-HOUSING | 1 | |
| 7M7410 | PLUG-PIPE | 1 | |
| 4727200 | 39 GASKET | 2 | |
| 4727201 | 40 GASKET-HOUSING | 2 |
