System And Components
4P-7800 TRANSFORMER GP-CURRENTS/N 6DA4802-UP; TAM1-UP
Group No: 4P-7800
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W3162 | 1 BRACKET | 1 | |
| 4P7798 | 2 TRANSFORMER | 1 | |
| 3K1649 | 3 STRIP-TERMINAL | 1 | |
| 3K8106 | 4 SCREW-MACHINE (8-32X1-IN) | 2 | |
| 4B2043 | 5 NUT (8-32-THD) | 2 | |
| 0S1618 | 6 BOLT (5/16-18X1-IN) | 4 | |
| 9M1974 | 7 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 5S0003 | 8 NUT (5/16-18-THD) | 4 | |
| 3N9364 | 9 MARKER | 1 | |
| 1P5121 | 10 SCREW-HEAD (5/16-18X1-IN) | 4 | |
| 9Y3846 | 11 COVER | 1 | |
| 7X1357 | 12 SPACER (4.22X9.52X6.35-MM THK) | 2 | |
| 9Y0931 | 13 MODULE AS | 1 | |
| 2P3203 | 14 BOLT-WASHER HEAD (3/8-16X1.25-IN) | 4 | |
| 5P1075 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 6V8801 | 16 NUT (3/8-16-THD) | 4 |
