System And Components
465-6747 PANEL GP-ELECTRONIC -EMCP 4.2S/N 6DA4802-UP
Group No: 465-6747
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1036272 | 1 SEAL | 1 | |
| 7C6121 | 2 MOUNT-FLEXIBLE | 2 | |
| 0960192 | 3 LOCKWASHER | 2 | |
| 1045604 | 4 WASHER (7.2X25X2-MM THK) | 2 | |
| 1057543 | 5 BLOCK-FUSE | 1 | |
| 1068916 | 6 BOLT (M6X1X16-MM) | 4 | |
| 1151322 | 7 TERMINAL (DOUBLE) | 8 | |
| 1152538 | 8 COVER-END | 1 | |
| 1165140 | 9 TERMINAL | 22 | |
| 1214722 | 10 STRIP-DUST SEAL | 3 | |
| 1250171 | 11 LOCK AS | 2 | |
| 1471960 | 12 RAIL | 1 | |
| 1267491 | 13 STRAP | 2 | |
| 1569340 | 14 SEAL | 4 | |
| 1663777 | 15 SCREW-BUTTON HEAD (M6X1X28-MM) | 4 | |
| 1783339 | 16 SCREW (8-32X0.5-IN) | 2 | |
| 1912276 | 17 SCREW-TRUSS HEAD (M5X0.8X20-MM) | 2 | |
| 1H3338 | 18 LOCKWASHER | 10 | |
| 2039007 | 19 NUT (1-1/2-18-THD) | 1 | |
| 2110089 | 20 NUT (1/4-20-THD) | 4 | |
| 2253322 | 21 SCREW-TRUSS HEAD (M6X1X10-MM) | 2 | |
| 2324673 | 22 PLUG | 1 | |
| 2449613 | 23 GASKET | 1 | |
| 2636468 | 24 PLUG-BUTTON | 3 | |
| 3E6924 | 25 SCREW-TRUSS HEAD (M6X1X50-MM) | 3 | |
| 2702679 | 26 LOCKWASHER | 1 | |
| 3118715 | 27 WASHER (5X11X1-MM THK) | 2 | |
| 3149101 | 28 BRACKET-END | 2 | |
| 3445673 | 29 NUT (M6X1-THD) | 12 | |
| 3680571 | 31 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 3E2286 | 32 STRIP-CONTACT | 2 | |
| 3E9865 | 33 LOCKNUT (1/4-20-THD) | 4 | |
| 3K6060 | 34 LOCKNUT (3/8-16-THD) | 2 | |
| 3N5611 | 35 MOUNT AS | 2 | |
| 3S2093 | 36 STRAP-CABLE | 15 | |
| 4395041 | 37 PANEL AS | 1 | |
| 3W4871 | NUT (6-32-THD) | 6 | |
| 7T1099 | LINK | 2 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 2 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 4 | |
| 1403943 | STUD (M6X1X16-MM) | 2 | |
| 4395042 | 38 PANEL AS | 1 | |
| 4395043 | 39 BOX AS-CONTROL | 1 | |
| 5P7846 | NUT-WELD (10-24-THD) | 6 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 7T1099 | LINK | 13 | |
| 4420635 | 40 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4431549 | 41 CONTROL GP-GENERATOR SET (EMCP 4.2) | 1 | |
| 4591873 | 42 MARKER AS-TERMINAL | 1 | |
| 4656748 | 43 HARNESS AS-PANEL | 1 | |
| 4B4274 | 45 WASHER (5.5X13X1.2-MM THK) | 12 | |
| 5716760 | 46 SPACER | 3 | |
| 5C2874 | 47 NUT (M5X0.8-THD) | 4 | |
| 5C8312 | 48 NUT (M4X0.7-THD) | 2 | |
| 5S3552 | 49 PLATE | 2 | |
| 6V1232 | 50 SCREW-BUTTON HEAD (8-32X9.52-MM) | 2 | |
| 8C7507 | 51 LOCKWASHER | 4 | |
| 8T2882 | 52 HANDLE-PULL | 1 | |
| 8T4205 | 53 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 8T4226 | 54 WASHER-PLATED (10.5X45X3-MM THK) | 4 | |
| 8T7922 | 55 SCREW-HEX SOCKET (10-24X0.383-IN) | 6 | |
| 8T9377 | 56 BOLT (3/8-16X2.25-IN) | 2 | |
| 8T9394 | 57 BOLT-SOCKET HEAD (10-24X0.5-IN) | 4 | |
| 9X8256 | 58 WASHER (6.6X12X2-MM THK) | 10 | |
| 9Y6027 | 59 FUSE-CERAMIC (10-AMPERE) | 1 | |
| 3559019 | ELECTRONICS GP-GENERATOR SET | 1 | |
| 5825898 | SOFTWARE GP-GENERATOR SET | 1 |
