System And Components
467-4168 PANEL GP-ELECTRONIC -EMCP 4.2S/N 6DA4802-UP
Group No: 467-4168
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1036272 | 1 SEAL | 1 | |
| 1H3338 | 2 LOCKWASHER | 6 | |
| 1057543 | 3 BLOCK-FUSE | 1 | |
| 1151322 | 4 TERMINAL (DOUBLE) | 8 | |
| 1152538 | 5 COVER-END | 1 | |
| 1165140 | 6 TERMINAL | 22 | |
| 1471960 | 7 RAIL | 1 | |
| 2039007 | 8 NUT (1-1/2-18-THD) | 1 | |
| 2088469 | 9 LOCKNUT (M6X1-THD) | 9 | |
| 2253322 | 10 SCREW-TRUSS HEAD (M6X1X10-MM) | 2 | |
| 3E6924 | 11 SCREW-TRUSS HEAD (M6X1X50-MM) | 3 | |
| 2702679 | 12 LOCKWASHER | 1 | |
| 3149101 | 13 BRACKET-END | 2 | |
| 3E2286 | 15 STRIP-CONTACT | 2 | |
| 3S2093 | 16 STRAP-CABLE | 15 | |
| 4420635 | 17 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4431549 | 18 CONTROL GP-GENERATOR SET (EMCP 4.2) | 1 | |
| 4571582 | 19 HARNESS AS-PANEL | 1 | |
| 4591873 | 20 MARKER AS-TERMINAL | 1 | |
| 4674169 | 21 HARNESS AS-PANEL | 1 | |
| 4996725 | 22 PLATE | 1 | |
| 5716760 | 23 SPACER | 3 | |
| 5C2890 | 24 NUT (M6X1-THD) | 2 | |
| 8T4205 | 25 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 9X8256 | 26 WASHER (6.6X12X2-MM THK) | 9 | |
| 9Y6027 | 27 FUSE-CERAMIC (10-AMPERE) | 1 | |
| 3559019 | ELECTRONICS GP-GENERATOR SET | 1 | |
| 5825898 | SOFTWARE GP-GENERATOR SET | 1 |
