System And Components
6N-2976 PANEL GP-INSTRUMENTS/N TAM1-UP
Group No: 6N-2976
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6H6699 | 1 ADAPTER (HEAT INDICATOR) | 1 | |
| 1S9593 | 2 STRAP-CABLE | 4 | |
| 2N0816 | 3 PANEL-INSTRUMENT | 1 | |
| 2660889 | 4 INDICATOR AS (FUEL PRESSURE) | 1 | |
| 2005233 | 5 GAUGE GP-COOLANT TEMPERATURE (WATER) | 1 | |
| 4B2049 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 1L6561 | 6 PLUG | 1 | |
| 6D3479 | 7 CLIP (LOOP) | 1 | |
| 7N3456 | 8 HOSE AS | 1 | |
| 6J3958 | 9 COUPLING-PIPE | 2 | |
| 0308142 | 10 REDUCER-FLARED | 1 | |
| 3R4437 | 11 NUT (9/16-18-THD) | 1 | |
| 0619258 | 12 TEE | 1 | |
| 2W3681 | 13 INDICATOR AS (ENGINE OIL PRESSURE) | 1 | |
| 8C3121 | 14 BOLT (5/16-18X1.5-IN) | 4 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 7W2731 | 15 RETAINER | 3 | |
| 5S7348 | 16 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B2041 | NUT (6-32-THD) | 2 | |
| 9B1117 | LOCKWASHER | 2 | |
| 3B6493 | 17 ELBOW | 1 | |
| 6N3171 | 18 COVER-PANEL | 1 | |
| 5M3062 | 19 BOLT (3/8-16X0.75-IN) | 2 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 2N5848 | 20 BASE AS | 1 | |
| 7X2501 | 21 BOLT (1/4-20X1.25-IN) | 3 | |
| 6V8185 | NUT (1/4-20-THD) | 3 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 3N4792 | 22 HOSE AS | 1 | |
| 3B9406 | 23 ELBOW-FLARED | 1 | |
| 8T2502 | 24 BOLT (3/8-16X1.125-IN) | 3 | |
| 4N1684 | 25 GASKET | 1 | |
| 6N8646 | 26 COVER | 1 | |
| 8N0415 | 27 BRACKET AS | 1 | |
| 6V3507 | 28 SEAL-RECTANGULAR | 3 | |
| 6V1813 | 29 FITTING | 1 | |
| 3S2093 | 30 STRAP-CABLE | 2 |
