System And Components
228-8646 DRIVE GP-FANS/N TXG9301-UP
Group No: 228-8646
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2432310 | 1 COVER | 1 | |
| 4W1203 | 2 CUP-BEARING | 2 | |
| 4W1204 | 3 CONE-BEARING | 2 | |
| 4W2042 | 4 SPACER (35.3X45.5X38.331-MM THK) | 1 | |
| 7E4808 | 5 PLATE | 1 | |
| 7E8540 | 6 BRACKET AS-FAN | 1 | |
| 7E5816 | SHAFT-FAN | 1 | |
| 3812511 | 7 BELT TENSIONER (FAN DRIVE) | 1 | |
| 3485434 | 9 IDLER AS | 1 | |
| 3300659 | 10 BELT-SERPENTINE | 1 | |
| 3076798 | 11 PULLEY-FAN (14-GROOVE) | 1 | |
| 2563867 | 12 ADAPTER-FAN | 1 | |
| 2A1531 | 13 BOLT (1/2-13X6.5-IN) | 1 | |
| 5M6214 | 14 PLUG (1/8-27 PTF) | 1 | |
| 5S9062 | 16 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 6H3956 | 17 PIN | 1 | |
| 6V9748 | 18 SEAL-LIP TYPE | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4178 | 21 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4183 | 22 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9B7237 | 25 BOLT (3/8-16X1.25-IN) | 6 | |
| 9F4446 | 26 SEAL-O-RING | 1 |
