System And Components
246-1048 HOUSING GP-FRONTS/N TXG1-UP; LHX1-99999
Group No: 246-1048
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C1445 | 1 COVER | 1 | |
| 1559524 | 2 SEAL-INTEGRAL | 1 | |
| 1669144 | 3 GASKET | 1 | |
| 1751483 | 4 HOUSING AS-FRONT | 1 | |
| 3E8044 | STUD (1/2-13X2.95-IN) | 1 | |
| 3539982 | 5 PLATE AS-FRONT HOUSING | 1 | |
| 0619455 | 6 SEAL-O-RING | 1 | |
| 0L2070 | 7 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1588 | 8 BOLT (3/8-16X1.25-IN) | 9 | |
| 0T0055 | 9 BOLT (3/8-16X4.25-IN)(MARKED X) | 9 | |
| 2B2695 | 10 BOLT (5/16-18X0.875-IN) | 2 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 30 | |
| 5P4255 | 12 BOLT-LOCKING (3/8-16X1-IN) | 8 | |
| 9M1974 | 13 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8S9191 | 14 BOLT (3/8-16X4-IN) | 1 | |
| 9S8752 | 15 NUT-FULL (3/8-16-THD) | 2 |
