System And Components
228-8647 AIR CLEANER GPS/N 86Z1-UP; 87Z1-UP
Group No: 228-8647
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N8817 | 1 BLOCK | 1 | |
| 8N1978 | 2 PRESCREENER AS (AIR CLEANER) | 1 | |
| 1454212 | 3 INDICATOR-AIR FILTER CHANGE | 1 | |
| 8S6824 | 4 CLAMP AS | 1 | |
| 8T6703 | 5 CLAMP-HOSE | 2 | |
| 9N0720 | 6 ELBOW-AIR INLET | 2 | |
| 2427406 | 7 HOSE | 1 | |
| 1004995 | 8 BODY AS-PRECLEANER | 1 | |
| 2487470 | 9 PIPE AS-AIR INLET | 1 | |
| 0S1591 | BOLT (3/8-16X1.5-IN) | 1 | |
| 6V8801 | NUT (3/8-16-THD) | 1 | |
| 2572672 | 10 TUBE AS | 1 | |
| 2632083 | 11 TUBE | 1 | |
| 2672822 | 12 AIR CLEANER GP | 1 | |
| 2768847 | 13 BRACKET AS | 2 | |
| 1984777 | 14 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 2338350 | 15 CLAMP (T-BOLT) | 6 | |
| 5P1076 | 16 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 6V8801 | 18 NUT (3/8-16-THD) | 2 | |
| 7X0772 | 19 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 8T2501 | 20 BOLT (3/8-16X2-IN) | 1 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T4956 | 23 BOLT (M12X1.75X35-MM) | 10 | |
| 7X0291 | 24 BOLT (3/8-16X3.75-IN) | 1 | |
| 5P1471 | 25 HOSE (58-CM) | ||
| 8S0023 | 26 CLIP (SLOT) | 1 | |
| 8S0024 | 27 CLIP (TAB) | 1 | |
| 3B6487 | 28 COUPLING (PIPE) | 1 | |
| 1454211 | 29 ADAPTER AS-FILTER | 1 | |
| 7J0204 | SEAL-O-RING | 1 |
