System And Components
228-8645 MUFFLER GPS/N 86Z1-UP; 87Z1-UP
Group No: 228-8645
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W7774 | 1 EJECTOR AS-EXHAUST | 1 | |
| 5L8854 | 2 RING-SEALING | 4 | |
| 7P4595 | 3 CLAMP | 1 | |
| 9L5839 | 4 COUPLING-EXHAUST | 2 | |
| 2315174 | 5 SUPPORT-EXHAUST | 2 | |
| 2368761 | 6 MUFFLER AS | 1 | |
| 2526242 | 7 SUPPORT AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2526243 | 8 TUBE AS | 1 | |
| 2645095 | 9 BRACKET AS | 1 | |
| 1099985 | EYE-LIFTING | 1 | |
| 1984777 | 10 WASHER-HARD (11X25X10-MM THK) | 13 | |
| 2N2765 | 11 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 4 | |
| 2N2766 | 12 LOCKNUT (3/8-16-THD) | 4 | |
| 4L6459 | 13 BOLT (3/8-16X2.5-IN) | 1 | |
| 5S7382 | 14 BOLT (3/8-16X1.375-IN) | 5 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 1 | |
| 8T2501 | 16 BOLT (3/8-16X2-IN) | 8 | |
| 8T4896 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 9N1941 | 18 CLAMP-V BAND | 2 |
