System And Components
342-5844 CONVERSION AR-MACHINES/N DBB642-650
Group No: 342-5844 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5R4467 | 1 RECEPTACLE AS | 1 | |
| 0T0642 | BOLT (3/8-24X0.625-IN) | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 2058317 | CAP AS | 1 | |
| 1083612 | 2 SPACER (11.13X19.05X53-MM THK) | 2 | |
| 1209071 | 3 BRACKET | 1 | |
| 1688280 | 4 SWITCH GP-START | 1 | |
| 3B4501 | LOCKWASHER | 1 | |
| 5L7200 | SCREW (8-32X0.375-IN) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 1720074 | KNOB | 1 | |
| 3094588 | 5 BRACKET AS | 1 | |
| 3094589 | 6 BRACKET | 1 | |
| 3221936 | 7 BUMPER AS-FRONT | 1 | |
| 3319993 | 8 CABLE AS (POSITIVE, RECEPTACLE) | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 5P0761 | CABLE (00-GA, RED) | 22 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 1355009 | TUBE-HEAT SHRINK (32-MM DIA) | 4 | |
| 3319994 | 9 CABLE AS (NEGATIVE, RECEPTACLE) | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 5P0747 | CABLE (00-GA, BLACK) | 12 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 1355009 | TUBE-HEAT SHRINK (32-MM DIA) | 4 | |
| 5C2874 | 10 NUT (M5X0.8-THD) | 4 | |
| 6V8189 | 11 NUT (5/16-18-THD) | 4 | |
| 8C7323 | 12 BOLT (3/8-16X6-IN) | 2 | |
| 8C8843 | 13 BOLT (1-8X4.5-IN) | 16 | |
| 8T0326 | 14 BOLT (M5X0.8X25-MM) | 4 | |
| 8T0328 | 15 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T5361 | 17 WASHER-HARD (28X49X5-MM THK) | 16 | |
| 8T9043 | 18 BOLT (5/16-18X0.875-IN) | 4 |
