System And Components
243-4549 FILTER GP-ENGINE OILS/N TXG726-UP; LHX3604-UP
Group No: 243-4549 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R1808 | 1 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 1 | |
| 2P3760 | 2 GASKET | 1 | |
| 2P3761 | 3 COVER | 1 | |
| 2P4301 | 4 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4305 | 5 GASKET | 2 | |
| 4N8150 | 6 SPRING | 1 | |
| 7C4038 | 7 COVER | 1 | |
| 3929208 | 8 PLUNGER-VALVE (RELIEF) | 1 | |
| 1910965 | 9 SHIELD-OIL FILTER | 1 | |
| 2598357 | 10 ADAPTER-OIL FILTER | 1 | |
| 0S1571 | 11 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 6 | |
| 0S1590 | 13 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 4 | |
| 2384664 | 15 STUD (3/8-16-THD) | 1 | |
| 3072671 | 16 PLUG AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3095131 | 17 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 3159840 | 18 ELBOW AS | 1 | |
| 6V8077 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3196208 | 19 ADAPTER AS | 1 | |
| 5P9617 | ADAPTER | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218649 | 20 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 7F9090 | 22 SCREW-DRIVE (NO 8X3/8-IN) | 2 | |
| 8C3445 | 23 CAP-DUST | 1 | |
| 9S8752 | 24 NUT-FULL (3/8-16-THD) | 4 |
