System And Components
272-0521 OIL CHANGE GP-HIGH SPEEDS/N DBB1-UP
Group No: 272-0521 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V2043 | 1 NUT-BULKHEAD (1-5/8-12-THD) | 1 | |
| 8W0968 | 2 HOSE AS | 1 | |
| 1209926 | 3 CLAMP | 2 | |
| 2229853 | 4 PLATE | 1 | |
| 1108827 | 5 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 1108826 | CAP-DUST | 1 | |
| 1488339 | 6 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488347 | 7 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 4M0061 | 8 BOLT (5/16-18X0.75-IN) | 1 | |
| 4S4455 | 9 CLIP | 1 | |
| 5P1075 | 10 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 5S7379 | 11 BOLT (3/8-16X0.875-IN) | 3 | |
| 6V8189 | 12 NUT (5/16-18-THD) | 1 | |
| 8S0948 | 13 CLIP | 1 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 3318540 | 15 CLIP (LOOP) | 1 |
