240-2759 COOLING ARS/N LHX1-8473

Group No: 240-2759 · Commonality

Part Number	Part Name	Qty
3S9643	2 SEAL-LIP TYPE (WATER TEMPERATURE REGULATOR)	2
4N1199	3 CLIP	1
4N3840	4 COVER	1
4N3841	5 GASKET	1
4N6257	6 ADAPTER	2
2485513	7 REGULATOR-WATER TEMPERATURE (92-DEG C)	2
1250434	9 SEAL-INTEGRAL	1
1264935	10 SEAL-INTEGRAL	2
1567896	11 ELBOW	1
1567900	12 TUBE	1
1662340	13 SEAL	1
1662795	14 BRACKET	1
1663501	15 PIPE	1
1704673	16 BONNET-INLET	1
2237962	17 CORE AS-OIL COOLER	1
2278851	18 MANIFOLD-HOUSING	1
2278852	19 COVER-WATER PUMP	1
2361687	20 HOUSING-REGULATOR	1
2413916	21 BONNET AS	1
3B0623	21A PLUG-CUP (25.73-MM OD)	1
0L1351	22 BOLT (3/8-16X0.875-IN)	1
0L1352	23 BOLT (3/8-16X3.25-IN)	1
0L2070	24 BOLT (3/8-16X2.25-IN)	2
0S1571	25 BOLT (3/8-16X1.75-IN)	2
0S1591	27 BOLT (3/8-16X1.5-IN)	4
0T0065	29 BOLT (3/8-16X3.5-IN)	1
1090077	30 SEAL-O-RING	5
1107753	31 SEAL-O-RING	2
1674407	32 SEAL-O-RING	1
1714358	33 SEAL-O-RING	2
1A2029	34 BOLT (3/8-16X1.125-IN)	8
2B2695	36 BOLT (5/16-18X0.875-IN)	2
4F0411	38 BOLT (3/8-16X6.5-IN)	3
5M2894	40 WASHER-HARD (10.2X18.5X2.5-MM THK)	3
6V5063	41 SEAL-O-RING	3
6V6609	42 SEAL-O-RING	4
7X7731	43 PLUG-PIPE (3/4-14-THD)	1
8T6761	45 PLUG-PIPE (1-11-1/2 NPT THD)	1
8T6767	46 PLUG-PIPE (3/8-18-THD)	1
9M1974	47 WASHER-HARD (8.8X16X2-MM THK)	2
9S4183	48 PLUG (1-1/16-12-THD)(STRAIGHT THREAD O-RING)	1
9S4185	49 PLUG (3/4-16-THD)(STRAIGHT THREAD O-RING)	4
