System And Components
240-2759 COOLING ARS/N TXG726-UP; LHX11121-UP
Group No: 240-2759 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M1974 | 1 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 3S9643 | 2 SEAL-LIP TYPE (WATER TEMPERATURE REGULATOR) | 2 | |
| 4N1199 | 3 CLIP | 1 | |
| 4N3840 | 4 COVER | 1 | |
| 4N3841 | 5 GASKET | 1 | |
| 4N6257 | 6 ADAPTER | 2 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 1250434 | 8 SEAL-INTEGRAL | 1 | |
| 1264935 | 9 SEAL-INTEGRAL | 2 | |
| 1567900 | 10 TUBE | 1 | |
| 1663501 | 11 PIPE | 1 | |
| 2237962 | 12 CORE AS-OIL COOLER (ENGINE OIL COOLER) | 1 | |
| 2264222 | 13 BONNET | 1 | |
| 2278851 | 14 MANIFOLD-HOUSING | 1 | |
| 2278852 | 15 COVER-WATER PUMP | 1 | |
| 2361687 | 16 HOUSING-REGULATOR | 1 | |
| 2413916 | 17 BONNET AS | 1 | |
| 3B0623 | PLUG-CUP (25.73-MM OD) | 1 | |
| 2485513 | 18 REGULATOR-WATER TEMPERATURE (92-DEG C)(WATER) | 2 | |
| 2901481 | 19 BRACKET | 1 | |
| 3017373 | 20 ELBOW | 1 | |
| 3411429 | 21 SEAL (HOUSING, REGULATOR) | 1 | |
| 3535126 | 22 PLUG AS | 5 | |
| 6V6609 | 22A SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3535140 | 23 PLUG AS | 1 | |
| 6V5063 | 23A SEAL-O-RING | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 3535144 | 24 PLUG AS | 1 | |
| 6V5064 | 24A SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 0L1351 | 25 BOLT (3/8-16X0.875-IN) | 1 | |
| 0L1352 | 26 BOLT (3/8-16X3.25-IN) | 1 | |
| 0L2070 | 27 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1571 | 28 BOLT (3/8-16X1.75-IN) | 2 | |
| 4F0411 | 29 BOLT (3/8-16X6.5-IN) | 3 | |
| 0S1591 | 30 BOLT (3/8-16X1.5-IN) | 4 | |
| 2B2695 | 31 BOLT (5/16-18X0.875-IN) | 2 | |
| 0T0065 | 32 BOLT (3/8-16X3.5-IN) | 1 | |
| 1090077 | 33 SEAL-O-RING | 4 | |
| 1107753 | 34 SEAL-O-RING | 2 | |
| 1674407 | 35 SEAL-O-RING | 1 | |
| 1714358 | 36 SEAL-O-RING | 2 | |
| 1A2029 | 37 BOLT (3/8-16X1.125-IN) | 8 | |
| 8T6767 | 38 PLUG-PIPE (3/8-18-THD) | 1 | |
| 2N6036 | COVER | 1 |
