System And Components
229-5350 RADIATOR GPS/N DBB1-UP
Group No: 229-5350 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y9236 | 1 GAUGE-SIGHT (COOLANT LEVEL) | 1 | |
| 2295438 | 2 TANK AS-COOLANT (RADIATOR BOTTOM) | 1 | |
| 2295442 | 3 CHANNEL AS | 1 | |
| 8D3508 | BOSS (3/8-16X1-IN) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 24 | |
| 9D9416 | BLOCK | 1 | |
| 2342493 | 4 TANK AS-COOLANT (RADIATOR TOP) | 1 | |
| 3L5893 | TUBE-OVERFLOW | 1 | |
| 7T1099 | LINK | 1 | |
| 8N8846 | NECK-FILLER | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 16 | |
| 2357036 | 5 CHANNEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 30 | |
| 2368140 | 6 CHANNEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 2368141 | 7 CHANNEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 2368142 | 8 CHANNEL | 1 | |
| 2375866 | 9 CHANNEL | 1 | |
| 2470152 | 10 PLATE | 1 | |
| 4653189 | 11 SEAL-RADIATOR | 4 | |
| 4653190 | 12 SEAL-RADIATOR | 2 | |
| 2943342 | 13 CAP-RADIATOR | 1 | |
| 4649039 | 14 CORE AS-RADIATOR (OUTSIDE) | 2 | |
| 4649048 | 15 CORE AS-RADIATOR (INSIDE) | 1 | |
| 7M8485 | 16 SEAL-O-RING | 1 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 72 | |
| 8T4133 | 18 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 60 | |
| 5P7211 | 20 SEAL (1.1-M EACH) | ||
| 1205281 | 21 SEAL (18-CM EACH) | ||
| 3122052 | 22 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 8T4195 | 23 BOLT (M10X1.5X30-MM) | 8 | |
| 3223187 | 24 BRACKET | 1 | |
| 3223186 | 25 BRACKET | 1 | |
| 1539516 | 26 SEAL (64-CM) | ||
| 8T6936 | 27 SEAL (2.2-M) |
