System And Components
222-8155 LINES GP-FUELS/N DBB1-664
Group No: 222-8155 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G4005 | 1 LINK | 2 | |
| 5D2645 | 2 CLAMP | 2 | |
| 5G5432 | 3 SPACER (10.5X16X18-MM THK) | 1 | |
| 5P4961 | 4 CLAMP-HOSE | 1 | |
| 6V8367 | 5 LOCKWASHER | 3 | |
| 8T5464 | 6 VALVE-BALL | 1 | |
| 8T9655 | 7 MOUNT-ISOLATION | 8 | |
| 9M9224 | 8 SPACER (0.406X0.75X1.688-IN THK) | 1 | |
| 1081610 | 9 CLAMP | 3 | |
| 2362254 | 10 HOSE AS | 1 | |
| 1761578 | 11 HOSE AS | 1 | |
| 1761579 | 12 HOSE AS | 1 | |
| 1909821 | 13 ELBOW AS | 1 | |
| 6V8989 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1911782 | 14 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 2156502 | 15 HOSE AS | 1 | |
| 2178342 | 16 PUMP GP-FUEL PRM & WATER SEP | 1 | |
| 2321374 | 17 BRACKET | 1 | |
| 2321376 | 18 SPACER (8.5X12.7X139.1-MM THK) | 2 | |
| 2364471 | 19 ANGLE | 1 | |
| 2364491 | 20 TUBE AS | 1 | |
| 2364492 | 21 TUBE AS | 1 | |
| 2364493 | 22 HOSE AS | 1 | |
| 2364494 | 23 HOSE AS | 1 | |
| 2375680 | 24 HOSE AS | 1 | |
| 2375681 | 25 HOSE AS | 1 | |
| 1488318 | 26 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488319 | 27 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8715 | CONNECTOR | 1 | |
| 1488345 | 28 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488367 | 29 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488374 | 30 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488377 | 31 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8980 | ELBOW | 1 | |
| 1488393 | 32 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1495452 | 33 UNION AS (STRAIGHT) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 1645619 | 34 PLUG AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 1646859 | 35 UNION AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9353 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1697409 | 36 UNION AS | 1 | |
| 6V8996 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1P4278 | 37 CLAMP-HOSE | 1 | |
| 1S0994 | 38 CLIP (LOOP) | 1 | |
| 2H3924 | 39 LOCKWASHER | 2 | |
| 3K0360 | 40 SEAL-O-RING | 1 | |
| 3S8664 | 41 CLIP | 3 | |
| 4L6454 | 42 BOLT (3/8-16X1-IN) | 4 | |
| 5K1094 | 43 LOCKWASHER | 1 | |
| 5K5338 | 44 CLIP (LOOP) | 5 | |
| 5P0059 | 45 BOLT (5/16-18X6-IN) | 2 | |
| 5P1075 | 46 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 5S7379 | 47 BOLT (3/8-16X0.875-IN) | 6 | |
| 8T2501 | 48 BOLT (3/8-16X2-IN) | 1 | |
| 6V8398 | 49 SEAL-O-RING | 1 | |
| 6V8801 | 50 NUT (3/8-16-THD) | 3 | |
| 6V9168 | 51 NUT (11/16-16-THD) | 3 | |
| 6V9169 | 52 NUT (13/16-16-THD) | 1 | |
| 6V9170 | 53 NUT-BULKHEAD (1-14-THD) | 2 | |
| 7X0290 | 54 BOLT (3/8-16X3.5-IN) | 1 | |
| 7X0579 | 55 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 8M2773 | 56 CLIP (LOOP) | 1 | |
| 8S0948 | 57 CLIP | 2 | |
| 8T1593 | 58 CLIP | 1 | |
| 8T4121 | 59 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4186 | 60 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4896 | 61 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 8T8912 | 62 BOLT (5/16-18X2.25-IN) | 1 | |
| 9X2091 | 63 ELBOW (SWIVEL) | 1 | |
| 8C6959 | 64 HOSE (28-CM) | ||
| 5P1442 | 65 HOSE (89-CM) |
