System And Components
222-8155 LINES GP-FUELS/N DBB665-UP
Group No: 222-8155 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 1 | |
| 3G4005 | 2 LINK | 2 | |
| 5P4961 | 3 CLAMP-HOSE | 1 | |
| 8T5464 | 4 VALVE-BALL | 1 | |
| 8T9655 | 5 MOUNT-ISOLATION | 8 | |
| 9M9224 | 6 SPACER (0.406X0.75X1.688-IN THK) | 1 | |
| 2362254 | 7 HOSE AS | 1 | |
| 1761578 | 8 HOSE AS | 1 | |
| 1761579 | 9 HOSE AS | 1 | |
| 1911782 | 10 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 2178342 | 11 PUMP GP-FUEL PRM & WATER SEP | 1 | |
| 2321374 | 12 BRACKET | 1 | |
| 2321376 | 13 SPACER (8.5X12.7X139.1-MM THK) | 2 | |
| 2364471 | 14 ANGLE | 1 | |
| 2364491 | 15 TUBE AS | 1 | |
| 2364492 | 16 TUBE AS | 1 | |
| 2364493 | 17 HOSE AS | 1 | |
| 2364494 | 18 HOSE AS | 1 | |
| 2464770 | 19 HOSE AS | 1 | |
| 3448019 | 20 HOSE AS | 1 | |
| 3461878 | 21 HOSE AS | 1 | |
| 1327551 | 22 SPACER (11X19X6-MM THK) | 1 | |
| 1488318 | 23 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488319 | 24 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8715 | CONNECTOR | 1 | |
| 1488345 | 25 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488367 | 26 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488374 | 27 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488377 | 28 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8980 | ELBOW | 1 | |
| 1488393 | 29 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1495452 | 30 UNION AS (STRAIGHT) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 1645619 | 31 PLUG AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 1646859 | 32 UNION AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9353 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1697409 | 33 UNION AS | 2 | |
| 6V8996 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1749599 | 34 STUD (3/8-16-THD) | 1 | |
| 1S0994 | 35 CLIP (LOOP) | 4 | |
| 2H3924 | 36 LOCKWASHER | 2 | |
| 3K0360 | 37 SEAL-O-RING | 1 | |
| 4D7733 | 38 CLIP (LOOP) | 10 | |
| 4L6454 | 39 BOLT (3/8-16X1-IN) | 4 | |
| 5K1094 | 40 LOCKWASHER | 1 | |
| 5M3062 | 41 BOLT (3/8-16X0.75-IN) | 3 | |
| 5P0059 | 42 BOLT (5/16-18X6-IN) | 2 | |
| 5P1075 | 43 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 5S7379 | 44 BOLT (3/8-16X0.875-IN) | 4 | |
| 5S7383 | 45 BOLT (3/8-16X1.75-IN) | 1 | |
| 6V8367 | 46 LOCKWASHER | 3 | |
| 6V8398 | 47 SEAL-O-RING | 1 | |
| 6V8801 | 48 NUT (3/8-16-THD) | 4 | |
| 6V9168 | 49 NUT (11/16-16-THD) | 3 | |
| 6V9169 | 50 NUT (13/16-16-THD) | 1 | |
| 6V9170 | 51 NUT-BULKHEAD (1-14-THD) | 2 | |
| 7X0290 | 52 BOLT (3/8-16X3.5-IN) | 1 | |
| 7X0579 | 53 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 8M2773 | 54 CLIP (LOOP) | 6 | |
| 8S0948 | 55 CLIP | 2 | |
| 8T1593 | 56 CLIP | 1 | |
| 8T4121 | 57 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4186 | 58 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4896 | 59 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 8T8912 | 60 BOLT (5/16-18X2.25-IN) | 1 | |
| 9C5344 | 61 SPACER (10.5X20X18-MM THK) | 1 | |
| 9X2091 | 62 ELBOW (SWIVEL) | 1 | |
| 8C6959 | 63 HOSE (28-CM) | ||
| 5P1442 | 64 HOSE (89-CM) | ||
| 5P8167 | 65 BOLT (3/8-16X0.625-IN) | 1 |
