System And Components
228-4441 LINES GP-FUELS/N LHX2720-2985
Group No: 228-4441 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T8902 | 1 ADAPTER-TEE | 1 | |
| 1085678 | 2 UNION | 1 | |
| 1230783 | 3 VALVE GP-FLUID SAMPLING (FUEL)(FUEL) | 1 | |
| 1688974 | 4 TUBE AS (FUEL SUPPLY) | 1 | |
| 1799348 | 5 VALVE-DRAIN | 1 | |
| 2747395 | 6 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 1979619 | 7 MANIFOLD GP-FUEL | 1 | |
| 2R6806 | 7A CONNECTOR | 2 | |
| 0336042 | SEAL-O-RING | 2 | |
| 8M0505 | 7B ADAPTER | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 2336742 | 8 VALVE GP-CHECK (FUEL) | 1 | |
| 2379310 | 9 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2392396 | 10 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2399938 | 11 HOSE AS | 1 | |
| 2418678 | 12 HOSE AS | 1 | |
| 2580883 | 13 SWITCH GP-PRESSURE (FUEL) | 1 | |
| 0336033 | 16 SEAL-O-RING | 1 | |
| 0336042 | 17 SEAL-O-RING | 1 | |
| 1488313 | 18 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 1488411 | 19 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1907634 | 20 SEAL-O-RING | 5 | |
| 0S1619 | 21 BOLT (3/8-16X3-IN) | 2 | |
| 1R0762 | 22 FILTER-FUEL (ADVANCED EFFICIENCY) | 1 | |
| 2R6806 | 23 CONNECTOR | 1 | |
| 3P1932 | 25 ADAPTER | 1 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8942 | 27 SEAL-O-RING | 4 | |
| 6V5048 | 28 SEAL-O-RING | 1 | |
| 6V8625 | 29 ELBOW | 1 | |
| 6V8636 | 30 CONNECTOR | 3 | |
| 6V8724 | 31 ELBOW | 1 | |
| 6V9829 | 32 CAP (ORFS) | 1 | |
| 8L2779 | 33 SEAL-O-RING | 1 | |
| 8L2786 | 34 SEAL-O-RING | 2 |
