System And Components
228-4441 LINES GP-FUELS/N LHX2985-25998
Group No: 228-4441 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V9829 | 1 CAP (ORFS) | 1 | |
| 3526498 | 2 TEE AS | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1085678 | 3 UNION | 1 | |
| 1230783 | 4 VALVE GP-FLUID SAMPLING (FUEL)(FUEL) | 1 | |
| 1688974 | 5 TUBE AS (FUEL SUPPLY) | 1 | |
| 1979619 | 9 MANIFOLD GP-FUEL | 1 | |
| 2336742 | 11 VALVE GP-CHECK (FUEL)(FUEL) | 1 | |
| 2379310 | 12 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2392396 | 13 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2399938 | 14 HOSE AS | 1 | |
| 2418678 | 16 HOSE AS | 1 | |
| 2580883 | 17 SWITCH GP-PRESSURE (FUEL) | 1 | |
| 2609235 | 18 VALVE AS-BALL (FUEL DRAIN) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2609233 | VALVE-BALL | 1 | |
| 2747395 | 19 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 3309732 | 22 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3072673 | 23 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 0S1619 | 26 BOLT (3/8-16X3-IN) | 2 | |
| 1R0762 | 27 FILTER-FUEL (ADVANCED EFFICIENCY) | 1 | |
| 3139614 | 28 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 4 | |
| 3218654 | 29 ADAPTER AS | 1 | |
| 3P1932 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 2147566 | 31 SEAL-O-RING | 1 | |
| 3196225 | 32 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1833399 | 33 CONNECTOR AS | 3 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2501424 | 34 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 |
