System And Components
355-0047 LINES GP-FUELS/N TXG726-UP; LHX25999-UP
Group No: 355-0047 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3218671 | 1 CONNECTOR AS | 1 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535102 | 2 FITTING AS-ELBOW | 1 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3526498 | 3 TEE AS | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1688974 | 4 TUBE AS (FUEL SUPPLY) | 1 | |
| 1979619 | 5 MANIFOLD GP-FUEL | 1 | |
| 2336742 | 6 VALVE GP-CHECK (FUEL)(FUEL) | 1 | |
| 2345013 | 7 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2353596 | 8 ADAPTER AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2353595 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2379310 | 9 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2399938 | 10 HOSE AS | 1 | |
| 2418678 | 11 HOSE AS | 1 | |
| 2751253 | 12 SWITCH GP-PRESSURE (DIFFERENTIAL) | 1 | |
| 2609235 | 13 VALVE AS-BALL (FUEL DRAIN) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2609233 | VALVE-BALL | 1 | |
| 2746719 | 14 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 0S1619 | 15 BOLT (3/8-16X3-IN) | 2 | |
| 1R0762 | 16 FILTER-FUEL (ADVANCED EFFICIENCY) | 1 | |
| 3072673 | 17 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3139614 | 18 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3196225 | 19 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309732 | 20 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1645567 | 21 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1833399 | 22 CONNECTOR AS | 3 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2501424 | 23 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 6V9829 | 24 CAP (ORFS) | 1 |
