System And Components
200-2232 ALTERNATOR GP-CHARGINGS/N DBB1-700
Group No: 200-2232 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4205 | 1 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1H3244 | 2 LOCKWASHER | 2 | |
| 6V8187 | 3 NUT (1/4-28-THD) | 1 | |
| 5S7349 | 4 BOLT (1/4-20X0.5-IN) | 1 | |
| 9L6770 | 5 CAP-DUST | 1 | |
| 2316133 | 6 KIT-BEARING (ALTERNATOR) | 1 | |
| 2316134 | 7 KIT-RECTIFIER (ALTERNATOR) | 1 | |
| 2022708 | 8 DIODE AS | 1 | |
| 3T6354 | 9 REGULATOR AS-VOLTAGE (24-VOLT)(ALTERNATOR) | 1 | |
| 2298906 | 10 CAPACITOR AS | 1 | |
| 2029897 | 11 BEARING-SPECIAL BALL | 1 | |
| 1006531 | 12 FAN-ALTERNATOR (11-BLADE) | 1 | |
| 1872034 | 13 NUT-FLANGE (5/8-18-THD) | 1 | |
| 2022783 | 14 PLATE | 1 | |
| 2027711 | 15 HOUSING AS | 1 | |
| 2027713 | 16 FRAME AS | 1 | |
| 2028647 | 17 STATOR AS | 1 | |
| 2022703 | 18 COIL AS | 1 | |
| 9S2390 | 19 RETAINER | 1 | |
| 9S2302 | 20 ROTOR AS | 1 | |
| 4B2047 | 21 NUT (10-24-THD) | 1 | |
| 8T0328 | 22 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8F1434 | 23 LOCKWASHER | 1 | |
| 2022784 | 24 KIT-ALTERNATOR TERMINAL (OUTPUT) | 1 | |
| 2022785 | 25 KIT-ALTERNATOR TERMINAL (RELAY) | 1 | |
| 2022786 | 26 KIT-ALTERNATOR TERMINAL (INDICATOR LIGHT) | 1 | |
| 2022787 | KIT-HARDWARE (ALTERNATOR) | 1 |
