System And Components
228-6878 BATTERY & WIRING GPS/N DBB1-249
Group No: 228-6878 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5169 | 1 GUARD-SWITCH | 1 | |
| 7K1181 | 2 STRAP-CABLE | 14 | |
| 1342252 | 3 SENSOR GP-TEMPERATURE (8-VOLT)(CONVERTER, RETARDER) | 1 | |
| 1342252 | 3A SENSOR GP-TEMPERATURE (8-VOLT)(HYDRAULIC TANK OIL) | 1 | |
| 1358659 | 4 GUARD | 1 | |
| 1392116 | 5 SWITCH GP-TOGGLE (ENGINE SHUTDOWN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1655970 | 6 SWITCH GP-TOGGLE (FUEL PRIMING PUMP) | 1 | |
| 2286824 | 7 WIRING GP-ENGINE | 1 | |
| 2286831 | 8 BATTERY & WIRING GP | 1 | |
| 2286983 | 9 WIRING GP-POWER TRAIN | 1 | |
| 2388665 | 10 SWITCH AS-PRESSURE (PARKING BRAKE AIR) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 9X1813 | SLEEVE | ||
| 2442182 | 11 WIRING GP-HITCH | 1 | |
| 2460479 | 12 HARNESS AS-FUEL TANK | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 2637125 | 13 HARNESS AS-CHASSIS | 1 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 9X4391 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 2 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1305300 | 14 CLIP | 7 | |
| 1S0994 | 15 CLIP (LOOP) | 1 | |
| 3J1907 | 16 SEAL-O-RING | 2 | |
| 4D7388 | 17 CLIP | 1 | |
| 4K8864 | 18 CLIP (LOOP) | 2 | |
| 4L6454 | 19 BOLT (3/8-16X1-IN) | 2 | |
| 4P7581 | 20 CLIP (LADDER) | 1 | |
| 4P8134 | 21 CLIP (LADDER) | 1 | |
| 5K5338 | 22 CLIP (LOOP) | 5 | |
| 5M3062 | 23 BOLT (3/8-16X0.75-IN) | 15 | |
| 5N2840 | 24 CLIP | 3 | |
| 5P1075 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5S7379 | 26 BOLT (3/8-16X0.875-IN) | 2 | |
| 6D4244 | 27 CLIP (LOOP) | 5 | |
| 6D4636 | 28 CLIP (LOOP) | 1 | |
| 6V8801 | 29 NUT (3/8-16-THD) | 1 | |
| 8M2770 | 30 CLIP (LOOP) | 4 | |
| 8T4896 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 8T9405 | 32 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 6V4589 | 33 SEAL-O-RING | 1 | |
| 6V5048 | 34 SEAL-O-RING | 2 | |
| 1085678 | 35 UNION | 1 | |
| 1946725 | 36 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2122768 | 37 SWITCH GP-PRESSURE (DIFFERENTIAL) | 1 |
