System And Components
228-6878 BATTERY & WIRING GPS/N DBB665-688
Group No: 228-6878 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5169 | 1 GUARD-SWITCH | 1 | |
| 3S2093 | 2 STRAP-CABLE | 4 | |
| 4P8221 | 3 BRACKET AS | 1 | |
| 9N5550 | BRACKET | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 7K1181 | 4 STRAP-CABLE | 15 | |
| 9L1566 | 5 SUPPORT | 1 | |
| 1342252 | 6 SENSOR GP-TEMPERATURE (8-VOLT)(CONVERTER, RETARDER) | 1 | |
| 1342252 | 6A SENSOR GP-TEMPERATURE (8-VOLT)(HYDRAULIC TANK OIL) | 1 | |
| 1358659 | 7 GUARD | 1 | |
| 1392116 | 8 SWITCH GP-TOGGLE (ENGINE SHUTDOWN) | 1 | |
| 1655970 | 9 SWITCH GP-TOGGLE (FUEL PRIMING PUMP) | 1 | |
| 1695414 | 10 CLIP | 1 | |
| 1772215 | 11 STRAP-DUAL CLAMP | 1 | |
| 1783620 | 12 STRAP-DUAL CLAMP | 1 | |
| 1933973 | 13 STRAP-CABLE | 4 | |
| 2006345 | 14 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2048000 | 15 MOUNTING-CABLE TIE | 2 | |
| 2286824 | 16 WIRING GP-ENGINE | 1 | |
| 2286831 | 17 BATTERY & WIRING GP | 1 | |
| 2286983 | 18 WIRING GP-POWER TRAIN | 1 | |
| 2388665 | 19 SWITCH AS-PRESSURE (PARKING BRAKE AIR) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 9X1813 | SLEEVE (15-CM) | ||
| 2442182 | 20 WIRING GP-HITCH | 1 | |
| 2460479 | 21 HARNESS AS-FUEL TANK | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 17 | |
| 1148843 | SLEEVE-PLASTIC (100-CM) | ||
| 1148844 | SLEEVE-PLASTIC (20-CM) | ||
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 3092491 | 22 HARNESS AS-CHASSIS | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 2 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 142 | |
| 8T8737 | PLUG-SEAL | 30 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 2 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 9X4391 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X5615 | SEAL (INTERFACE, 70-PIN) | 2 | |
| 1148843 | SLEEVE-PLASTIC (80-CM) | ||
| 1148844 | SLEEVE-PLASTIC (40-CM) | ||
| 1148845 | SLEEVE-PLASTIC (40-CM) | ||
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1305300 | 23 CLIP | 6 | |
| 1488313 | 24 ADAPTER AS | 2 | |
| 5P6944 | ADAPTER | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3J1907 | 25 SEAL-O-RING | 2 | |
| 4D7388 | 26 CLIP | 1 | |
| 4K8864 | 27 CLIP (LOOP) | 1 | |
| 4L6454 | 28 BOLT (3/8-16X1-IN) | 5 | |
| 4L6459 | 29 BOLT (3/8-16X2.5-IN) | 1 | |
| 4L9337 | 30 BOLT (3/8-16X1.5-IN) | 1 | |
| 4P7581 | 31 CLIP (LADDER) | 2 | |
| 4P8134 | 32 CLIP (LADDER) | 3 | |
| 5M3062 | 33 BOLT (3/8-16X0.75-IN) | 7 | |
| 5N2840 | 34 CLIP | 1 | |
| 5P1075 | 35 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P7854 | 36 CLIP (LOOP) | 2 | |
| 5S7379 | 37 BOLT (3/8-16X0.875-IN) | 5 | |
| 6D4244 | 38 CLIP (LOOP) | 4 | |
| 6D4636 | 39 CLIP (LOOP) | 1 | |
| 6V8801 | 40 NUT (3/8-16-THD) | 1 | |
| 6W6672 | 41 SPACER (10.5X20X38-MM THK) | 1 | |
| 8M2770 | 42 CLIP (LOOP) | 1 | |
| 8M2773 | 43 CLIP (LOOP) | 3 | |
| 8T4896 | 44 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 |
