System And Components
213-6318 PANEL GP-CIRCUIT BREAKERS/N DBB1-UP
Group No: 213-6318 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 9F8125 | 2 LOCKWASHER | 4 | |
| 9R7941 | 3 SOCKET AS | 1 | |
| 9R7980 | COVER | 1 | |
| 1251302 | 4 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 1712210 | 5 CIRCUIT BREAKER AS (80-AMPERE)(ALTERNATOR) | 1 | |
| 1712210 | 5A CIRCUIT BREAKER AS (80-AMPERE)(MAIN) | 1 | |
| 2532111 | LOCKWASHER | 2 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1984432 | 6 HARNESS AS-PANEL | 1 | |
| 9X1343 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 9X0145 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 8N1517 | RECEPTACLE AS-CONNECTOR (25-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN)(START RELAY) | 1 | |
| 1987751 | 7 PANEL AS | 1 | |
| 2094561 | 8 PLATE AS | 1 | |
| 2094562 | 9 PLATE AS | 1 | |
| 2138661 | 10 COVER | 1 | |
| 2171571 | 11 FILM-IDENTIFICATION (CIRCUIT BREAKER) | 1 | |
| 1305300 | 12 CLIP | 1 | |
| 1325789 | 13 CLIP (LADDER) | 1 | |
| 1H4393 | 14 LOCKWASHER | 2 | |
| 0684209 | 15 SCREW (8-32X0.75-IN) | 2 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 1 | |
| 5L4507 | 17 SCREW-MACHINE (10-32X0.875-IN) | 4 | |
| 6T3643 | 18 CIRCUIT BREAKER AS (15-AMPERE)(ENGINE ECM) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 7X2536 | 19 BOLT (M8X1.25X14-MM) | 2 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4138 | 22 BOLT (M6X1X20-MM) | 2 | |
| 8T4171 | 23 BOLT (M6X1X12-MM) | 2 | |
| 8T4224 | 24 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8256 | 25 WASHER (6.6X12X2-MM THK) | 4 | |
| 9R7935 | 26 WASHER-SHOULDER (18.5X27X2-MM THK) | 1 |
